Is Julia taking over Python in Data Science?
Waasif Nadeem
| August 4, 2022

This blog will discuss the strengths and limitations of Python and Julia to address a very common topic of debate; is Julia better than Python?

It is a high-level programming language that was designed in 2012, specifically for the Data Science and Machine Learning community. It was introduced as a mathematically oriented language and became popular for its speed and performance over other languages like Python and R.

Almost every introductory level course on Julia talks about its speed compared to Python, NumPy, and C, claiming that the performance of this language is as good as the speed of C. Also, it outperforms Python and NumPy but only by a margin. This leads to another debate; Will Julia conquer Python’s kingdom in Data Science?

To be able to address this question, let us dive deeper to compare several aspects of the two languages.

python_julia
Python_Julia

Popularity and community

Python has been operational for over 30 years and is one of the most popular programming languages right now with a large developer community offering solutions and help for potential problems. This makes Python much easier and more convenient to use than any other language.

Julia has a small but rapidly growing and active community. Even though the number of followers is constantly increasing for it; the majority of support is still provided by the writers themselves. It is expected that when the scope of this programming language expands outside of data science, the popularity of the language will increase.

Speed

It takes leverage upon other languages when it comes to its execution speed. It is a compiled language primarily written on its own base. Well-written code in it can be as fast as in C. It is an excellent solution for challenges related to data analysis and statistical computing.

Python is an interpreted language that is not famous for its speed. Self-implemented functions in Python can take a lot longer to compile as compared to Julia or C. Therefore, it uses libraries like NumPy, Sklearn, and TensorFlow to implement different functions and algorithms. These libraries provide implementations of algorithms that are much faster than Python but slower than Julia.

Libraries

Python offers an extensive range of libraries that can be simply imported, and their functions can be used. Python is also supported by a large number of third-party libraries.

Julia does not have much in its library collection and the packages are not very well maintained. This makes some implementations like neural networks a bit tedious. Due to the lack of libraries, the scope of it is also limited, as many tasks like web development cannot be performed with this language yet. However, considering the expectations of the growing community, we can expect more developed and well-maintained libraries from it soon.

Code conversion

One of the most fascinating features of Julia is converting code from other programming languages to it. It is a very straightforward process that is widely supported.

In Python, code conversion is much more difficult than in Julia, but it is still possible. Julia’s code can be shared with Python using the module named “PyCall.”

Linear algebra (Data Science algorithms)

Julia was made with the intention of being used in statistics and machine learning. It offers various methods and algorithms for linear algebra. These methods are quite easy to implement, and their syntax is very similar to mathematical expressions.

Python does not have its own pre-defined methods for linear algebra, so users work through libraries, such as NumPy for such implementations. These implementations are, however, not as simple to use as in Julia.

Will Julia replace Python?

It would be too early to say that Julia will replace Python in Data Science. Both have their respective advantages. It depends on your use case and preference.

Python has built the trust of its community for years, and it is not an easy task for Julia to announce itself in that community. But it is not impossible either. As the community of this language grows, more support would be available for people. With the growth in resources, maybe in the near future, This language would be a new norm in Data Science.

Upgrade your data science skillset with our Python for Data Science and Data Science Bootcamp training!

Quickly learn drone programming in 10 minutes
Ebad Ullah Khan
| October 19, 2022

In this blog, we will be learning how to program some basic movements in a drone with the help of Python. The drone we will use is Dji Tello. We will learn drone programming with Scratch, Swift, and even Python.

 A step-by-step guide to learning drone programming

We will go step by step through how to issue commands through the Wi-Fi network

drone programming
Drone – Data Science Dojo



Installing Python libraries

First, we will need some Python libraries installed onto our laptop. Let’s install them with the following two commands:



pip install djitellopy

pip install opencv-python



The djitellopy is a python library making use of the official Tello sdk. The second command is to install opencv which will help us to look through the camera of the drone. Some other libraries this program will make use of are ‘keyboard’ and ‘time’. After installation, we import them into our project



import keyboard as kp

from djitellopy import tello

import time

import cv2



 Read more about Machine Learning using Python in cloud

Connection

We must first instantiate the Tello class so we can use it afterward. For the following commands to work, we must switch the drone to On and find and connect to the Wi-Fi network generated by it on our laptop. The tel.connect() command lets us connect the drone to our program. After the connection of the drone to our laptop is successful, the following commands can be executed.



tel = tello.Tello()
tel.connect()





Sending ending commands to the drone

We will build a function which will send movement commands to the drone.

def getKeyboardInput(img):

    kp.init()

    lr, fb, ud, yv = 0, 0, 0, 0

    speed = 50

    if kp.getKey("LEFT"):

        lr = -speed

    elif kp.getKey("RIGHT"):

        lr = speed



    if kp.getKey("UP"):

        fb = speed

    elif kp.getKey("DOWN"):

        fb = -speed



    if kp.getKey("w"):

        ud = speed

    elif kp.getKey("s"):

        ud = -speed

   

    if kp.getKey("a"):

        yv = speed

    elif kp.getKey("d"):

        yv = -speed



    if kp.getKey("l"):

        tel.land()

    if kp.getKey("t"):

        tel.takeoff()



    if kp.getKey("z"):

        cv2.imwrite("Resources/images/{time.time}.jpg", img)

        time.sleep(0.05)

    return [lr, fb, ud, yv]

tel.streamon()





The drone takes 4 inputs to move so we first take four values and assign a 0 to them. The speed must be set to an initial value for the drone to take off. Now we map the keyboard keys to our desired values and assign those values to the four variables. For example, if the keyboard key is “LEFT” then assign the speed with a value of -50. If the “RIGHT” key is pressed, then assign a value of 50 to the speed variable, and so on. The code block below explains how to map the keyboard keys to the variables:

if kp.getKey("LEFT"):

        lr = -speed

    elif kp.getKey("RIGHT"):

        lr = speed





This program also takes two extra keys for landing and taking off (l and t). A keyboard key “z” is also assigned if we want to take a picture from the drone. As the drone’s video will be on, whenever we click on “z” key, opencv will save the image in a folder specified by us. After providing all the combinations, we must return the values in a 1D array. Also, don’t forget to run tel.streamon() to turn on the video streaming.

We must make the drone take commands until and unless we press the “l” key for landing. So, we have a while True loop in the following code segment:



Calling the function



while True:

    img = tel.get_frame_read().frame

    img = cv2.resize(img,(360,360))

    cv2.imshow('Picture',img)

    cv2.waitKey(1)

    vals = getKeyboardInput(img)

    tel.send_rc_control(vals[0],vals[1],vals[2],vals[3])

    time.sleep(0.05)







The get_frame_read() function reads the video frame by frame (just like an image) so we can resize it and show it on the laptop screen. The process will be so fast that it will completely look like a video being displayed.

The last thing we must do is to call the function we created above. Remember, we have a list being returned from it. Each value of the list must be sent as a separate index value to the send_rc_control method of the tel object



Execution



Before running the code, confirm that the laptop is connected to the drone via Wi-Fi.

Now, execute the python file and then press “t” for the drone to take off. From there, you can press the keyboard keys for it to move in your desired direction. When you want the drone to take pictures, press “z” and when you want it to land, press “l”



Conclusion



In this blog, we learned how to issue basic keyboard commands for the drone to move. Furthermore, we can also add more keys for inbuilt Tello functions like “flip” and “move away”. Videos can be captured from the drone and stored locally on our laptop

Umair Hasan
| September 26, 2022

In this tutorial, you will learn how to create an attractive voice-controlled chatbot application with a small amount of coding in python. To build our application we’ll first create a good-looking user interface through the built-in Tkinter library in Python and then we will create some small functions to achieve our task.



Here is a sneak peek of what we are going to create.



Voice controlled chatbot
Voice controlled chatbot using coding in Python – Data Science Dojo

Before kicking off, I hope you already have a brief idea about web scraping, if not then read the following article talking about Python web scraping



PRO-TIP: Join our 5-day instructor-led Python for Data Science training to enhance your deep learning



Pre-requirements for building a voice chatbot

Make sure that you are using Python 3.8+ and the following libraries are installed on it

  • Pyttsx3 (pyttsx3 is a text-to-speech conversion library in Python)
  • SpeechRecognition (Library for performing speech recognition)
  • Requests (The requests module allows you to send HTTP requests using Python)
  • Bs4 (Beautiful Soup is a library that is used to scrape information from web pages)
  • pyAudio (With PyAudio, you can easily use Python to play and record audio)



If you are still facing installation errors or incompatibility errors, then you can try downloading specific versions of the above libraries as they are tested and working currently in the application.



  • Python 3.10
  • pyttsx3==2.90
  • SpeechRecognition==3.8.1
  • requests==2.28.1
  • beautifulsoup4==4.11.1
  • beautifulsoup4==4.11.1



Now that we have set everything it is time to get started. Open a fresh new py file and name it VoiceChatbot.py. Import the following relevant libraries on the top of the file.



  • from tkinter import *
  • import time
  • import datetime
  • import pyttsx3
  • import speech_recognition as sr
  • from threading import Thread
  • import requests
  • from bs4 import BeautifulSoup



The code is divided into the GUI section, which uses the Tkinter library of python and 7 different functions. We will start by declaring some global variables and initializing instances for text-to-speech and Tkinter. Then we start creating the windows and frames of the user interface.



The user interface

This part of the code loads images initializes global variables, and instances and then it creates a root window that displays different frames. The program starts when the user clicks the first window bearing the background image.



if __name__ == “__main__”:



#Global Variables

loading = None
query = None
flag = True
flag2 = True



#initalizng text to speech and setting properties

engine = pyttsx3.init() # Windows voices = engine.getProperty('voices') engine.setProperty('voice', voices[1].id) rate = engine.getProperty('rate') engine.setProperty('rate', rate-10)



#loading images

    img1= PhotoImage(file='chatbot-image.png')
    img2= PhotoImage(file='button-green.png')
    img3= PhotoImage(file='icon.png')
    img4= PhotoImage(file='terminal.png')
    background_image=PhotoImage(file="last.png")
    front_image = PhotoImage(file="front2.png")



#creating root window

    root=Tk()
    root.title("Intelligent Chatbot")
    root.geometry('1360x690+-5+0')
    root.configure(background='white')



#Placing frame on root window and placing widgets on the frame

    f = Frame(root,width = 1360, height = 690)
    f.place(x=0,y=0)
    f.tkraise()



#first window which acts as a button containing the background image

    okVar = IntVar()
    btnOK = Button(f, image=front_image,command=lambda: okVar.set(1))
    btnOK.place(x=0,y=0)
    f.wait_variable(okVar)
    f.destroy()
    background_label = Label(root, image=background_image)
    background_label.place(x=0, y=0)



#Frame that displays gif image

    frames = [PhotoImage(file='chatgif.gif',format = 'gif -index %i' %(i)) for i in range(20)]
    canvas = Canvas(root, width = 800, height = 596)
    canvas.place(x=10,y=10)
    canvas.create_image(0, 0, image=img1, anchor=NW)



#Question button which calls ‘takecommand’ function

    question_button = Button(root,image=img2, bd=0, command=takecommand)
    question_button.place(x=200,y=625)



#Right Terminal with vertical scroll

    frame=Frame(root,width=500,height=596)
    frame.place(x=825,y=10)
    canvas2=Canvas(frame,bg='#FFFFFF',width=500,height=596,scrollregion=(0,0,500,900))
    vbar=Scrollbar(frame,orient=VERTICAL)
    vbar.pack(side=RIGHT,fill=Y)
    vbar.config(command=canvas2.yview)
    canvas2.config(width=500,height=596, background="black")
    canvas2.config(yscrollcommand=vbar.set)
    canvas2.pack(side=LEFT,expand=True,fill=BOTH)
    canvas2.create_image(0,0, image=img4, anchor="nw")
    task = Thread(target=main_window)
    task.start()
    root.mainloop()



The main window functions

This is the first function that is called inside a thread. It first calls the wishme function to wish the user. Then it checks whether the query variable is empty or not. If the query variable is empty, then it checks the contents of the query variable. If there is a shutdown or quit or stop word in query, then it calls the shutdown function, and the program exits. Else, it calls the web_scraping function. This function calls another function with the name wishme.



def main_window():
    global query
    wishme()
    while True:
        if query != None:
            if 'shutdown' in query or 'quit' in query or 'stop' in query or 'goodbye' in query:
                shut_down()
                break
            else:
                web_scraping(query)
                query = None



The wish me function

This function checks the current time and greets users according to the hour of the day and it also updates the canvas. The contents in the text variable are passed to the ‘speak’ function. The ‘transition’ function is also invoked at the same time in order to show the movement effect of the bot image, while the bot is speaking. This synchronization is achieved through threads, which is why these functions are called inside threads.



def wishme():
    hour = datetime.datetime.now().hour
    if 0 <= hour < 12:
        text = "Good Morning sir. I am Jarvis. How can I Serve you?"
    elif 12 <= hour < 18:
        text = "Good Afternoon sir. I am Jarvis. How can I Serve you?"
    else:
        text = "Good Evening sir. I am Jarvis. How can I Serve you?"
    canvas2.create_text(10,10,anchor =NW , text=text,font=('Candara Light', -25,'bold italic'), fill="white",width=350)
    p1=Thread(target=speak,args=(text,))
    p1.start()
    p2 = Thread(target=transition)
    p2.start()



The speak function

This function converts text to speech using pyttsx3 engine.

def speak(text):
    global flag
    engine.say(text)
    engine.runAndWait()
    flag=False



The transition functions

The transition function is used to create the GIF image effect, by looping over images and updating them on canvas. The frames variable contains a list of ordered image names.



def transition():
    global img1
    global flag
    global flag2
    global frames
    global canvas
    local_flag = False
    for k in range(0,5000):
        for frame in frames:
            if flag == False:
                canvas.create_image(0, 0, image=img1, anchor=NW)
                canvas.update()
                flag = True
                return
            else:
                canvas.create_image(0, 0, image=frame, anchor=NW)
                canvas.update()
                time.sleep(0.1)



The web scraping function

This function is the heart of this application. The question asked by the user is then searched on google using the ‘requests’ library of python. The ‘beautifulsoap’ library extracts the HTML content of the page and checks for answers in four particular divs. If the webpage does not contain any of the four divs, then it searches for answers on Wikipedia links, however, if that is also not successful, then the bot apologizes.



def web_scraping(qs):
    global flag2
    global loading
    URL = 'https://www.google.com/search?q=' + qs
    print(URL)
    page = requests.get(URL)
    soup = BeautifulSoup(page.content, 'html.parser')
    div0 = soup.find_all('div',class_="kvKEAb")
    div1 = soup.find_all("div", class_="Ap5OSd")
    div2 = soup.find_all("div", class_="nGphre")
    div3  = soup.find_all("div", class_="BNeawe iBp4i AP7Wnd")

    links = soup.findAll("a")
    all_links = []
    for link in links:
       link_href = link.get('href')
       if "url?q=" in link_href and not "webcache" in link_href:
           all_links.append((link.get('href').split("?q=")[1].split("&sa=U")[0]))

    flag= False
    for link in all_links:
       if 'https://en.wikipedia.org/wiki/' in link:
           wiki = link
           flag = True
           break
    if len(div0)!=0:
        answer = div0[0].text
    elif len(div1) != 0:
       answer = div1[0].text+"\n"+div1[0].find_next_sibling("div").text
    elif len(div2) != 0:
       answer = div2[0].find_next("span").text+"\n"+div2[0].find_next("div",class_="kCrYT").text
    elif len(div3)!=0:
        answer = div3[1].text
    elif flag==True:
       page2 = requests.get(wiki)
       soup = BeautifulSoup(page2.text, 'html.parser')
       title = soup.select("#firstHeading")[0].text
       paragraphs = soup.select("p")
       for para in paragraphs:
           if bool(para.text.strip()):
               answer = title + "\n" + para.text
               break
    else:
        answer = "Sorry. I could not find the desired results"
    canvas2.create_text(10, 225, anchor=NW, text=answer, font=('Candara Light', -25,'bold italic'),fill="white", width=350)
    flag2 = False
    loading.destroy()
    p1=Thread(target=speak,args=(answer,))
    p1.start()
    p2 = Thread(target=transition)
    p2.start()



The take command function

This function is invoked when the user clicks the green button to ask any question. The speech recognition library listens for 5 seconds and converts the audio input to text using google recognize API.



def takecommand():
    global loading
    global flag
    global flag2
    global canvas2
    global query
    global img4
    if flag2 == False:
        canvas2.delete("all")
        canvas2.create_image(0,0, image=img4, anchor="nw")
    speak("I am listening.")
    flag= True
    r = sr.Recognizer()
    r.dynamic_energy_threshold = True
    r.dynamic_energy_adjustment_ratio = 1.5
    #r.energy_threshold = 4000
    with sr.Microphone() as source:
        print("Listening...")
        #r.pause_threshold = 1
        audio = r.listen(source,timeout=5,phrase_time_limit=5)
        #audio = r.listen(source)

    try:
        print("Recognizing..")
        query = r.recognize_google(audio, language='en-in')
        print(f"user Said :{query}\n")
        query = query.lower()
        canvas2.create_text(490, 120, anchor=NE, justify = RIGHT ,text=query, font=('fixedsys', -30),fill="white", width=350)
        global img3
        loading = Label(root, image=img3, bd=0)
        loading.place(x=900, y=622)

    except Exception as e:
        print(e)
        speak("Say that again please")
        return "None"



The shutdown function

This function farewells the user and destroys the root window in order to exit the program.

def shut_down():
    p1=Thread(target=speak,args=("Shutting down. Thankyou For Using Our Sevice. Take Care, Good Bye.",))
    p1.start()
    p2 = Thread(target=transition)
    p2.start()
    time.sleep(7)
   root.destroy()



Conclusion

It is time to wrap up, I hope you enjoyed our little application. This is the power of Python, you can create small attractive applications in no time with a little amount of code. Keep following us for more cool python projects!



Code - CTA



Austin Chia
| September 22, 2022

Data science tools are becoming increasingly popular as the demand for data scientists increases. However, with so many different tools, knowing which ones to learn can be challenging

In this blog post, we will discuss the top 7 data science tools that you must learn. These tools will help you analyze and understand data better, which is essential for any data scientist.

So, without further ado, let’s get started!

List of 7 data science tools

There are many tools a data scientist must learn, but these are the top 7:

Top 7 data science tools - Data Science Dojo
Top 7 data science tools you must learn
  • Python
  • R Programming
  • SQL
  • Java
  • Apache Spark
  • Tensorflow
  • Git

And now, let me share about each of them in greater detail!

1. Python

Python is a popular programming language that is widely used in data science. It is easy to learn and has many libraries that can be used to analyze data, machine learning, and deep learning.

It has many features that make it attractive for data science: An intuitive syntax, rich libraries, and an active community.

Python is also one of the most popular languages on GitHub, a platform where developers share their code.

Therefore, if you want to learn data science, you must learn Python!

There are several ways you can learn Python:

  • Take an online course: There are many online courses that you can take to learn Python. I recommend taking several introductory courses to familiarize yourself with the basic concepts.



PRO TIP: Join our 5-day instructor-led Python for Data Science training to enhance your deep learning skills.



  • Read a book: You can also pick up a guidebook to learning data science. They’re usually highly condensed with all the information you need to get started with Python programming.
  • Join a Boot Camp: Boot camps are intense, immersive programs that will teach you Python in a short amount of time.



Whichever way you learn Python, make sure you make an effort to master the language. It will be one of the essential tools for your data science career.

2. R Programming

R is another popular programming language that is highly used among statisticians and data scientists. They typically use R for statistical analysis, data visualization, and machine learning.

R has many features that make it attractive for data science:

  • A wide range of packages
  • An active community
  • Great tools for data visualization (ggplot2)

These features make it perfect for scientific research!

In my experience with using R as a healthcare data analyst and data scientist, I enjoyed using packages like ggplot2 and tidyverse to work on healthcare and biological data too!

If you’re going to learn data science with a strong focus on statistics, then you need to learn R.

To learn R, consider working on a data mining project or taking a certificate in data analytics.



3. SQL

SQL (Structured Query Language) is a database query language used to store, manipulate, and retrieve data from data sources. It is an essential tool for data scientists because it allows them to work with databases.

SQL has many features that make it attractive for data science: it is easy to learn, can be used to query large databases, and is widely used in industry.

If you want to learn data science involving big data sets, then you need to learn SQL. SQL is also commonly used among data analysts if that’s a career you’re also considering exploring.

There are several ways you can learn SQL:

  • Take an online course: There are plenty of SQL courses online. I’d pick one or two of them to start with
  • Work on a simple SQL project
  • Watch YouTube tutorials
  • Do SQL coding questions



4. Java

Java is another programming language to learn as a data scientist. Java can be used for data processing, analysis, and NLP (Natural Language Processing).

Java has many features that make it attractive for data science: it is easy to learn, can be used to develop scalable applications, and has a wide range of frameworks commonly used in data science. Some popular frameworks include Hadoop and Kafka.

There are several ways you can learn Java:



5. Apache Spark

Apache Spark is a powerful big data processing tool that is used for data analysis, machine learning, and streaming. It is an open-source project that was originally developed at UC Berkeley’s AMPLab.

Apache Spark is known for its uses in large-scale data analytics, where data scientists can run machine learning on single-node clusters and machines.

Spark has many features made for data science:

  • It can process large datasets quickly
  • It supports multiple programming languages
  • It has high scalability
  • It has a wide range of libraries

If you want to learn big data science, then Apache Spark is a must-learn. Consider taking an online course or watching a webinar on big data to get started.



6. Tensorflow

TensorFlow is a powerful toolkit for machine learning developed by Google. It allows you to build and train complex models quickly.

Some ways TensorFlow is useful for data science:

  • Provides a platform for data automation
  • Model monitoring
  • Model training

Many data scientists use TensorFlow with Python to develop machine learning models. TensorFlow helps them to build complex models quickly and easily.

If you’re interested to learn TensorFlow, do consider these ways:

  • Read the official documentation
  • Complete online courses
  • Attend a TensorFlow meetup

However, to learn and practice your Tensorflow skills, you’ll need to pick up decent deep learning hardware to support the running of your algorithms.



7. Git

Git is a version control system used to track code changes. It is an essential tool for data scientists because it allows them to work on projects collaboratively and keep track of their work.

Git is useful in data science for:

If you’re planning to enter data science, Git is a must-know tool! Since you’ll be coding a lot in Python/R/Java, you’ll want to master Git to work with your team well in a collaborative coding environment.

Git is also an essential part of using GitHub, a code repository platform used by many data scientists.

To learn Git, I’d recommend just watching simple tutorials on YouTube.

Final thoughts

And these are the top seven data science tools that you must learn!

The most important thing is to get started and keep upskilling yourself! There is no one-size-fits-all solution in data science, so find the tools that work best for you and your team and start learning.

I hope this blog post has been helpful in your journey to becoming a data scientist. Happy learning!



Ali Mohsin
| August 3, 2022

Data Science Dojo has launched  Jupyter Hub for Deep Learning using Python offering to the Azure Marketplace with pre-installed Deep Learning libraries and pre-cloned GitHub repositories of famous Deep Learning books and collections which enables the learner to run the example codes provided.

What is Deep Learning?

Deep learning is a subfield of machine learning and artificial intelligence (AI) that mimics how people gain specific types of knowledge. Deep learning algorithms are incredibly complex and the structure of these algorithms, where each neuron is connected to the other and transmits information, is quite similar to that of the nervous system. Also, there are different types of neural networks to address specific problems or datasets, for example, Convolutional neural networks (CNNs) and Recurrent neural networks (RNNs). While in the field of Data Science, which also encompasses statistics and predictive modeling, contains deep learning as a key component. This procedure is made quicker and easier by deep learning, which is highly helpful for data scientists who are tasked with gathering, processing, and interpreting vast amounts of data.

Deep Learning using Python

Python, a high-level programming language that was created in 1991 and has seen a rise in popularity, is compatible with deep learning, which has contributed to its development. While several languages, including C++, Java, and LISP, can be used with deep learning, Python continues to be the preferred option for millions of developers worldwide.

Additionally, data is the essential component in all deep learning algorithms and applications, both as training data and as input. Python is a great tool to employ for managing large volumes of data for training your deep learning system, inputting input, or even making sense of its output because it is primarily used for data management, processing, and forecasting.

PRO TIP: Join our 5-day instructor-led Python for Data Science training to enhance your deep learning skills.

deep learning

Challenges for individuals

Individuals who want to upgrade their path from Machine Learning to Deep Learning and want to start with it usually lack the resources to gain hands-on experience with Deep Learning. A beginner in Deep Learning also faces compatibility issues while installing libraries.

What we provide

Jupyter Hub for Deep Learning using Python solves all the challenges by providing you an effortless coding environment in the cloud with pre-installed Deep Learning python libraries which reduces the burden of installation and maintenance of tasks hence solving the compatibility issues for an individual.

Moreover, this offer provides the user with repositories of famous authors and books on Deep Learning which contain chapter-wise notebooks with some exercises which serve as a learning resource for a user in gaining hands-on experience with Deep Learning.

The heavy computations required for Deep Learning applications are not performed on the user’s local machine. Instead, they are performed in the Azure cloud, which increases responsiveness and processing speed.

Listed below are the pre-installed python libraries related to Deep learning and the sources of repositories of Deep Learning books provided by this offer:

Python libraries:

  • NumPy
  • Matplotlib
  • Pandas
  • Seaborn
  • TensorFlow
  • Tflearn
  • PyTorch
  • Keras
  • Scikit Learn
  • Lasagne
  • Leather
  • Theano
  • D2L
  • OpenCV

Repositories:

  • GitHub repository of book Deep Learning with Python 2nd Edition, by author François Chollet.
  • GitHub repository of book Hands-on Deep Learning Algorithms with Python, by author Sudharsan Ravichandran.
  • GitHub repository of book Hands-on Machine Learning with Scikit-Learn, Keras, and TensorFlow, by author Geron Aurelien.
  • GitHub repository of collection on Deep Learning Models, by author Sebastian Raschka.

Conclusion:

Jupyter Hub for Deep Learning using Python provides an in-browser coding environment with just a single click, hence providing ease of installation. Through this offer, a user can work on a variety of Deep Learning applications self-driving cars, healthcare, fraud detection, language translations, auto-completion of sentences, photo descriptions, image coloring and captioning, object detection, and localization.

This Jupyter Hub for Deep Learning instance is ideal to learn more about Deep Learning without the need to worry about configurations and computing resources. The heavy resource requirement to deal with large datasets and perform the extensive model training and analysis for these applications is no longer an issue as heavy computations are now performed on Microsoft Azure which increases processing speed.

At Data Science Dojo, we deliver data science education, consulting, and technical services to increase the power of data. We are therefore adding a free Jupyter Notebook Environment dedicated specifically to Deep Learning using Python. Install the Jupyter Hub offer now from the Azure Marketplace, your ideal companion in your journey to learn data science!

Try Now!

Syed Saad Peerzada
| August 4, 2022

What is web scraping?

Web scraping is the act of extracting the content and data from a website. The vast amount of data available on the internet is not open and available to download. As a result, ethical web scraping is the most effective technique to collect this data. There is also a debate about the legality of web scraping as the content may get stolen or the website can crash as a result of web scraping.

Ethical Web Scraping is the act of harvesting data legally by following ethical rules about web scraping. There are certain rules in ethical web scraping that when followed ensure trust between the website owner and web scraper.

Web scraping using Python

In Python, a learner can write a small piece of code to do large tasks. Since web scraping is used to save time, a small code written in Python can save a lot of time. Also, Python is simple and easy to understand and provides an extensive set of libraries for web scraping and further manipulation required on extracted data.

PRO TIP: Join our 5-day instructor-led Python for Data Science training to enhance your web scraping skills.

Challenges for individuals

Individuals who are new to web scraping and wish to flourish in their field usually lack the necessary computing and learning resources to obtain hands-on expertise. Also, they may face compatibility issues when installing libraries.

What we provide

With just a single click, Jupyter Hub for Ethical Web Scraping using Python comes with pre-installed Web Scraping python libraries, which gives the learner an effortless coding environment in the Azure cloud and reduces the burden of installation. Moreover, this offer provides the learner with a repository of the famous book on web scraping which contains chapter-wise notebooks which serve as a learning resource for a user in gaining hands-on experience with web scraping.

Through this offer, a learner can collect data from various sources legally by following the best practices for ethical web scraping mentioned in the latter section of this blog. Once the data is collected, it can be further analyzed to get valuable insights into almost everything while all the heavy computations are performed on Microsoft Azure hence saving the user from the trouble of running high computations on the local machine.

Python libraries:

Listed below are the pre-installed web scraping python libraries and the sources of repositories of web scraping book provided by this offer:

  •          Pandas
  •          NumPy
  •          Scikit-learn
  •          Beautifulsoup4
  •          lxml
  •          MechanicalSoup
  •          Requests
  •          Scrapy
  •          Selenium
  •          urllib

Repository:

  •          GitHub repository of book Web Scraping with Python 2nd Edition,
    by author Ryan Mitchell.

Best practices for ethical web scraping

Globally, there is a debate about whether web scraping is an ethical concept or not. The reason it is unethical is that when a website is queried repeatedly by the same user (in this case bot), too many requests land on the server simultaneously and all resources of the server may be consumed in generating responses for each request, preventing it from responding to other legitimate users.

In this way, the server denies responses to any further users, commonly known as a Denial of Service (DoS) attack.

Below are the best practices for ethical web scraping, and compliance with these will allow a web scraper to work ethically.

1.   Check out for ROBOTS.TXT

Robots.txt file, also known as the Robots Exclusion Standard, is used to inform the web scrapers if the website can be crawled or not, if yes then how to index the website. A legitimate web scraper is expected to respect the instructions in this file and not disobey the website owner’s allowed instructions.

2.   Check for website APIs

An ethical web scraper is expected to first look for the public API of the website in question instead of scraping it all together. Many website owners provide public API access which can be used by anyone looking to gain from the information available on the website. Provision of public API works in the best interests of both the ethical scrapper as well as the website owner, avoiding web scraping altogether.

3.   Avoid repeated requests

Vigorous scraping can occasionally cause functionality issues, resulting in a poor user experience for humans. As a result, it is always advised to scrape during off-peak hours. An ethical web scraper is expected to delay recurrent requests to avoid a DoS attack.

4.   Provide your identity

It is always a good idea to take responsibility for one’s actions. An ethical web scraper never hides his or her identity and provides it in a user-agent string. Not only does this make the intentions of the scraper clear but also provides a means of contact for any questions or concerns of the website owner.

5.   Avoid fake ownership

The content scraped through web scraper should always be respected and never passed on under the fake information of scraper as the author. This act can be regarded as highly unethical as well as illegal since the website owner may file a copyright claim. It also damages the reputation of genuine web scrapers and hurts the trust of the website owner.

6.  Ask for permission

Since the website information belongs to the owner, one should never presume it to be free and ask politely to use it for their means. An ethical web scraper always seeks permission from the website owner to avoid any future problems. The website owner should be given the choice of whether she agrees to scrape the data.

 7.  Give due credit

To encourage the website owner as a token of thanks, the web scraper should give due credit wherever possible. This can be done in many ways such as providing a link to the original website on any blog, article, or social media post by generating traffic for the original website.

Ethical web scraping

Conclusion

Ethical web scraping is a two-way street in which the website owner should be mindful of the global availability of the data, similarly, the scraper should not harm the website in any way and also first seek permission from the website owner. If a web scraper abides by the above-mentioned practices, I.e., he/she works ethically, the web owner may not only allow scraping his or her website but also provide helpful means to the scraper in the form of Meta data or a public API.

At Data Science Dojo, we deliver data science education, consulting, and technical services to increase the power of data. We are therefore adding a free Jupyter Notebook Environment dedicated specifically for Ethical Web Scraping using Python. Install the Jupyter Hub offer now from the Azure Marketplace by Data Science Dojo, your ideal companion in your journey to learn data science!

Try now - CTA

Aadam Nadeem
| September 12, 2022

The Monte Carlo method is a technique for solving complex problems using probability and random numbers. Through repeated random sampling, Monte Carlo calculates the probabilities of multiple possible outcomes occurring in an uncertain process.

Whenever you try to solve problems in the future, you make certain assumptions. For example, forecasting problems make certain assumptions like the cost of a particular item, the value of stocks, or electricity units used in the future. Since these problems try to predict an estimate of an unknown value based on historical data, there always exists inherent risk and uncertainty.

The Monte Carlo simulation allows us to see all the possible outcomes of our decisions and assess risk, consequently allowing for better decision-making under uncertainty.

This blog will walk through the famous Monty Hall problem, and how it can be solved using the Monte Carlo method using Python.

Monty Hall problem

In the Monty Hall problem, the TV show host Monty presents three doors to the participant. Behind one of the doors is a valuable prize like a car, while behind the others is a less valuable prize like a goat.

Consider yourself to be one of the participants in the show. You choose one out of the three doors. Before opening your chosen door, Monty opens another door behind which would be one of the goats. Now you are left with two doors, behind one could be the car, and behind the other would be the other goat.

Monty then gives you the option to either switch your answer to the other unopened door or stick to the original one.

Is it in your favor to switch your answer to the other door? Well, probability says it is!

Let’s see how:

Initially, there are three unopen doors in front of you. The probability of the car being behind any of these doors is 1/3.



Monte Carlo - Probability



Let’s say you decide to pick door #1 as the probability is the same (1/3) for each of these doors. In other words, the probability that the car is behind door #1 is 1/3, and the probability that it will be behind either door #2 or door #3 is 2/3.





Monte Carlo - Probability



Monty is aware of the prize behind each door. He chooses to open door #3 and reveal a goat. He then asks you if you would like to either switch to door #2 or stick with door #1.



Monte Carlo Probability



To solve the problem, let’s switch to Python and apply the Monte Carlo simulation.

Solving with Python

Initialize the 3 prizes

Python lists



Create python lists to store the probabilities after each game. We will play as many games as iterations input.



Probability using Python



Monte Carlo simulation

Before starting the game, we randomize the prizes behind each door. One of the doors will have a car behind it, while the other two will have a goat each. When we play a large number of games, all possible permutations get covered of prize distributions, and door choices get covered.



Monte Carlo Simulations



Below is the code that decides if your choice was correct or not, and if switching would’ve been the correct move.



Python code for Monte Carlo





 After playing each game, the winning probabilities are updated and stored in the lists. When all games have been played, we return the final values of each of the lists, i.e., winning by switching your choice and winning by sticking to your choice.



calculating probabilities with Python



Get results

Enter your desired number of iterations (the higher the number, the more numbers of games will be played to approximate the probabilities). In the final step, plot your results.



Probability - Python code



After running the simulation 1000 times, the probability that we win by always switching is 67.7%, and the probability that we win by always sticking to our choice is 32.3%. In other words, you will win approximately 2/3 times if you switch your door, and only 1/3 times if you stick to the original door.



Probability results



Therefore, according to the Monte Carlo simulation, we are confident that it works to our advantage to switch the door in this tricky game.



Graphs play a very important role in the data science workflow. Learn how to create dynamic professional-looking plots with Plotly.py.

We use plots to understand the distribution and nature of variables in the data and use visualizations to describe our findings in reports or presentations to both colleagues and clients. The importance of plotting in a data scientist’s work cannot be overstated.

Learn more about visualizing your data at Data Science Dojo’s Introduction to Python for Data Science!

Plotting with Matplotlib

If you have worked on any kind of data analysis problem in Python you will probably have encountered matplotlib, the default (sort of) plotting library. I personally have a love-hate relationship with it — the simplest plots require quite a bit of extra code but the library does offer flexibility once you get used to its quirks. The library is also used by pandas for its built-in plotting feature. So even if you haven’t heard of matplotlib, if you’ve used df.plot(), then you’ve unknowingly used matplotlib.

Plotting with Seaborn

Another popular library is seaborn, which is essentially a high-level wrapper around matplotlib and provides functions for some custom visualizations, these require quite a bit of code to create in the standard matplotlib. Another nice feature seaborn provides is sensible defaults for most options like axis labels, color schemes, and sizes of shapes.

Introducing Plotly

Plotly might sound like the new kid on the block, but in reality, it’s nothing like that. Plotly originally provided functionality in the form of a JavaScript library built on top of D3.js and later branched out into frontends for other languages like R, MATLAB and, of course, Python. plotly.py is the Python interface to the library.

As for usability, in my experience Plotly falls in between matplotlib and seaborn. It provides a lot of the same high-level plots as seaborn but also has extra options right there for you to tweak, such as matplotlib. It also has generally much better defaults than matplotlib.

Plotly’s interactivity

The most fascinating feature of Plotly is the interactivity. Plotly is fundamentally different from both matplotlib and seaborn because plots are rendered as static images by both of them while Plotly uses the full power of JavaScript to provide interactive controls like zooming in and panning out of the visual panel. This functionality can also be extended to create powerful dashboards and responsive visualizations that could convey so much more information than a static picture ever could.

First, let’s see how the three libraries differ in their output and complexity of code. I’ll use common statistical plots as examples.

To have a relatively even playing field, I’ll use the built-in seaborn theme that matplotlib comes with so that we don’t have to deduct points because of the plot’s looks.

fig, ax = plt.subplots(figsize=(8,6))

for species, species_df in iris.groupby('species'):
    ax.scatter(species_df['sepal_length'], species_df['sepal_width'], label=species);

ax.set(xlabel='Sepal Length', ylabel='Sepal Width', title='A Wild Scatterplot appears');
ax.legend();



Wild Scatterplot



fig, ax = plt.subplots(figsize=(8,6))

sns.scatterplot(data=iris, x='sepal_length', y='sepal_width', hue='species', ax=ax);

ax.set(xlabel='Sepal Length', ylabel='Sepal Width', title='A Wild Scatterplot appears');



statistical plot



fig = go.FigureWidget()

for species, species_df in iris.groupby('species'):
    fig.add_scatter(x=species_df['sepal_length'], y=species_df['sepal_width'],
                    mode='markers', name=species);

fig.layout.hovermode = 'closest'
fig.layout.xaxis.title = 'Sepal Length'
fig.layout.yaxis.title = 'Sepal Width'
fig.layout.title = 'A Wild Scatterplot appears'
fig
scatterplot



Looking at the plots, the matplotlib and seaborn plots are basically identical, the only difference is in the amount of code. The seaborn library has a nice interface to generate a colored scatter plot based on the hue argument, but in matplotlib we are basically creating three scatter plots on the same axis. The different colors are automatically assigned in both (default color cycle but can also be specified for customization). Other relatively minor differences are in the labels and legend, where seaborn creates these automatically. This, in my experience, is less useful than it seems because very rarely do datasets have nicely formatted column names. Usually they contain abbreviations or symbols so you still have to assign ‘proper’ labels.

But we really want to see what Plotly has done, don’t we? This time I’ll start with the code. It’s eerily similar to matplotlib, apart from not sharing the exact syntax of course and the hovermode option. Hovering? Does that mean…? Yes, yes it does. Moving the cursor over a point reveals a tooltip showing the coordinates of the point and the class label. The tooltip can also be customized to show other information about the particular point. To the top right of the panel, there are controls to zoom, select and pan across the plot. The legend is also interactive, it acts sort of like checkboxes. You can click on a class to hide/show all the points of that class.

Since the amount or complexity of code isn’t that drastically different from the other two options and we get all these interactivity options, I’d argue this is basically free benefits.

fig, ax = plt.subplots(figsize=(8,6))

grouped_df = iris.groupby('species').mean()
ax.bar(grouped_df.index.values,
       grouped_df['sepal_length'].values);

ax.set(xlabel='Species', ylabel='Average Sepal Length', title='A Wild Barchart appears');



wild bar chart



fig, ax = plt.subplots(figsize=(8,6))

sns.barplot(data=iris, x='species', y='sepal_length', estimator=np.mean, ax=ax);

ax.set(xlabel='Species', ylabel='Average Sepal Length', title='A Wild Barchart appears');



bar chart - Python plots



fig = go.FigureWidget()

grouped_df = iris.groupby('species').mean()
fig.add_bar(x=grouped_df.index, y=grouped_df['sepal_length']);

fig.layout.xaxis.title = 'Species'
fig.layout.yaxis.title = 'Average Sepal Length'
fig.layout.title = 'A Wild Barchart appears'
fig



bar chart - python plot



The bar chart story is similar to the scatter plots. In this case, again, seaborn provides the option within the function call to specify the metric to be shown on the y axis using the x variable as the grouping variable. For the other two, we have to do this ourselves using pandasPlotly still provides interactivity out of the box.

Now that we’ve seen that Plotly can hold its own against our usual plotting options, let’s see what other benefits it can bring to the table. I will showcase some trace types in Plotly that are useful in a data science workflow, and how interactivity can make them more informative.

Heatmaps

fig = go.FigureWidget()

cor_mat = car_crashes.corr()
fig.add_heatmap(z=cor_mat,
                x=cor_mat.columns,
                y=cor_mat.columns,
                showscale=True)

fig.layout.width = 500
fig.layout.height = 500
fig.layout.yaxis.automargin = True
fig.layout.title = 'A Wild Heatmap appears'
fig



heatmap - python

Heatmaps are commonly used to plot correlation or confusion matrices. As expected, we can hover over the squares to get more information about the variables. I’ll paint a picture for you. Suppose you have trained a linear regression model to predict something from this dataset. You can then show the appropriate coefficients in the hover tooltips to get a better idea of which correlations in the data the model has captured.

Parallel coordinates plot

fig = go.FigureWidget()

parcords = fig.add_parcoords(dimensions=[{'label':n.title(),
                                          'values':iris[n],
                                          'range':[0,8]} for n in iris.columns[:-2]])

fig.data[0].dimensions[0].constraintrange = [4,8]
parcords.line.color = iris['species_id']
parcords.line.colorscale = make_plotly(cl.scales['3']['qual']['Set2'], repeat=True)

parcords.line.colorbar.title = ''
parcords.line.colorbar.tickvals = np.unique(iris['species_id']).tolist()
parcords.line.colorbar.ticktext = np.unique(iris['species']).tolist()
fig.layout.title = 'A Wild Parallel Coordinates Plot appears'
fig



parralel coordinates plot .gif



I suspect some of you might not yet be familiar with this visualization, as I wasn’t a few months ago. This is a parallel coordinates plot of four variables. Each variable is shown on a separate vertical axis. Each line corresponds to a row in the dataset and the color obviously shows which class that row belongs to. A thing that should jump out at you is that the class separation in each variable axis is clearly visible. For instance, the Petal_Length variable can be used to classify all the Setosa flowers very well.

Since the plot is interactive, the axes can be reordered by dragging to explore interconnectedness between the classes and how it affects the class separations. Another interesting interaction is the constrained range widget (the bright pink object on the Sepal_Length axis). It can be dragged up or down to decolor the plot. Imagine having these on all axes and finding a sweet spot where only one class is visible. As a side note, the decolored plot has a transparency effect on the lines so the density of values can be seen.

A version of this type of visualization also exists for categorical variables in Plotly. It is called Parallel Categories.

Choropleth plot

fig = go.FigureWidget()

choro = fig.add_choropleth(locations=gdp['CODE'],
                           z=gdp['GDP (BILLIONS)'],
                           text = gdp['COUNTRY'])

choro.marker.line.width = 0.1
choro.colorbar.tickprefix = '$'
choro.colorbar.title = 'GDP<br>Billions US$'
fig.layout.geo.showframe = False
fig.layout.geo.showcoastlines = False
fig.layout.title = 'A Wild Choropleth appears<br>Source:\
                    <a href="https://www.cia.gov/library/publications/the-world-factbook/fields/2195.html">\
                    CIA World Factbook</a>'
fig



Choropleth | Data Science Dojo



A choropleth is a very commonly used geographical plot. The benefit of the interactivity should be clear in this one. We can only show a single variable using the color but the tooltip can be used for extra information. Zooming in is also very useful in this case, allowing us to look at the smaller countries. The plot title contains HTML which is being rendered properly. This can be used to create fancier labels.

Interactive scatter plot

fig = go.FigureWidget()

scatter_trace = fig.add_scattergl(x=diamonds['carat'], y=diamonds['price'],
                                  mode='markers', marker={'opacity':0.2});

fig.layout.hovermode = 'closest'
fig.layout.xaxis.title = 'Carat'
fig.layout.yaxis.title = 'Price'
fig.layout.title = 'A Wild Scatterplot appears'
fig



scatterplot



I’m using the scattergl trace type here. This is a version of the scatter plot which uses WebGL in the background so that the interactions don’t get laggy even with larger datasets.

There is quite a bit of over-plotting here even with the aggressive transparency, so let’s zoom into the densest part to take a closer look. Zooming in reveals that the carat variable is quantized and there are clean vertical lines.

def selection_handler(trace, points, selector):
    data_mean = np.mean(points.ys)
    fig.data[0].figure.layout.title.text = f'A Wild Scatterplot appears - mean price: ${data_mean:.1f}'
fig.data[0].on_selection(selection_handler)

fig



scatter plot



Selecting a bunch of points in this scatter plot will change the title of the plot to show the mean price of the selected points. This could prove to be very useful in a plot where there are groups and you want to visually see some statistics of a cluster.

This behavior is easily implemented using callback functions attached to predefined event handlers for each trace.

More interactivity

Let’s do something fancier now.

fig1 = go.FigureWidget()
fig1.add_scattergl(x=exports['beef'], y=exports['total exports'],
                   text=exports['state'],
                   mode='markers');
fig1.layout.hovermode = 'closest'
fig1.layout.xaxis.title = 'Beef Exports in Million US$'
fig1.layout.yaxis.title = 'Total Exports in Million US$'
fig1.layout.title = 'A Wild Scatterplot appears'

fig2 = go.FigureWidget()
fig2.add_choropleth(locations=exports['code'],
                    z=exports['total exports'].astype('float64'),
                    text=exports['state'],
                    locationmode='USA-states')
fig2.data[0].marker.line.width = 0.1
fig2.data[0].marker.line.color = 'white'
fig2.data[0].marker.line.width = 2
fig2.data[0].colorbar.title = 'Exports Millions USD'
fig2.layout.geo.showframe = False
fig2.layout.geo.scope = 'usa'
fig2.layout.geo.showcoastlines = False
fig2.layout.title = 'A Wild Choropleth appears'

def do_selection(trace, points, selector):
    if trace is fig2.data[0]:
        fig1.data[0].selectedpoints = points.point_inds
    else:
        fig2.data[0].selectedpoints = points.point_inds
fig1.data[0].on_selection(do_selection)
fig2.data[0].on_selection(do_selection)

HBox([fig1, fig2])



scatterplot choropleth linked



We have already seen how to make scatter and choropleth plots so let’s put them to use and plot the same data-frame. Then, using the event handlers we also saw before, we can link both plots together and interactively explore which states produce which kinds of goods.

This kind of interactive exploration of different slices of the dataset is far more intuitive and natural than transforming the data in pandas and then plotting it again.

fig = go.FigureWidget()
fig.add_histogram(x=iris['sepal_length'],
                  histnorm='probability density');
fig.layout.xaxis.title = 'Sepal Length'
fig.layout.yaxis.title = 'Probability Density'
fig.layout.title = 'A Wild Histogram appears'

def change_binsize(s):
    fig.data[0].xbins.size = s
slider = interactive(change_binsize, s=(0.1,1,0.1))
label = Label('Bin Size: ')

VBox([HBox([label, slider]),
      fig])



histogram



Using the ipywidgets module’s interactive controls different aspects of the plot can be changed to gain a better understanding of the data. Here the bin size of the histogram is being controlled.

fig = go.FigureWidget()

scatter_trace = fig.add_scattergl(x=diamonds['carat'], y=diamonds['price'],
                                  mode='markers', marker={'opacity':0.2});

fig.layout.hovermode = 'closest'
fig.layout.xaxis.title = 'Carat'
fig.layout.yaxis.title = 'Price'
fig.layout.title = 'A Wild Scatterplot appears'

def change_opacity(x):
    fig.data[0].marker.opacity = x
slider = interactive(change_opacity, x=(0.1,1,0.1))
label = Label('Marker Opacity: ')

VBox([HBox([label, slider]),
      fig])



scatter opacity



The opacity of the markers in this scatter plot is controlled by the slider. These examples only control the visual or layout aspects of the plot. We can also change the actual data which is being shown using dropdowns. I’ll leave you to explore that on your own.

What have we learned about Python plots

Let’s take a step back and sum up what we have learned. We saw that Plotly can reveal more information about our data using interactive controls, which we get for free and with no extra code. We saw a few interesting, slightly more complex visualizations available to us. We then combined the plots with custom widgets to create custom interactive workflows.

All this is just scratching the surface of what Plotly is capable of. There are many more trace types, an animations framework, and integration with Dash to create professional dashboards and probably a few other things that I don’t even know of.



Ali Mohsin
| July 7, 2022

Data Science Dojo has launched Jupyter Hub for Data Visualization using Python offering to the Azure Marketplace with pre-installed data visualization libraries and pre-cloned GitHub repositories of famous books, courses, and workshops which enable the learner to run the example codes provided.

What is data visualization?

It is a technique that is utilized in all areas of science and research. We need a mechanism to visualize the data so we can analyze it because the business sector now collects so much information through data analysis. By providing it with a visual context through maps or graphs, it helps us understand what the information means. As a result, it is simpler to see trends, patterns, and outliers within huge data sets because the data is easier for the human mind to understand and pull insights from the data.

Data visualization using Python

It may assist by conveying data in the most effective manner, regardless of the industry or profession you have chosen. It is one of the crucial processes in the business intelligence process, takes the raw data, models it, and then presents the data so that conclusions may be drawn. Data scientists are developing machine learning algorithms in advanced analytics to better combine crucial data into representations that are simpler to comprehend and interpret.

Given its simplicity and ease of use, Python has grown to be one of the most popular languages in the field of data science over the years. Python has several excellent visualization packages with a wide range of functionality for you whether you want to make interactive or fully customized plots.

PRO TIP: Join our 5-day instructor-led Python for Data Science training to enhance your visualization skills.

Data visualization using Python
Using Python to visualize Data

Challenges for individuals

Individuals who want to visualize their data and want to start visualizing data using some programming language usually lack the resources to gain hands-on experience with it. A beginner in visualization with programming language also faces compatibility issues while installing libraries.

What we provide

Our Offer, Jupyter Hub for Visualization using Python solves all the challenges by providing you with an effortless coding environment in the cloud with pre-installed Data Visualization python libraries which reduces the burden of installation and maintenance of tasks hence solving the compatibility issues for an individual.

Additionally, our offer gives the user access to repositories of well-known books, courses, and workshops on data visualization that include useful notebooks which is a helpful resource for the users to get practical experience with data visualization using Python. The heavy computations required for applications to visualize data are not performed on the user’s local machine. Instead, they are performed in the Azure cloud, which increases responsiveness and processing speed.   

Listed below are the pre-installed data visualization using python libraries and the sources of repositories of a book to visualize data, a course, and a workshop provided by this offer:

Python libraries:

  • NumPy
  • Matplotlib
  • Pandas
  • Seaborn
  • Plotly
  • Bokeh
  • Plotnine
  • Pygal
  • Ggplot
  • Missingno
  • Leather
  • Holoviews
  • Chartify
  • Cufflinks

Repositories:

  • GitHub repository of the book Interactive Data Visualization with Python, by author Sharath Chandra Guntuku, AbhaBelorkar, Shubhangi Hora, Anshu Kumar.
  • GitHub repository of Data Visualization Recipes in Python, by Theodore Petrou.
  • GitHub repository of Python data visualization workshop, by Stefanie Molin (Author of “Hands-On Data Analysis with Pandas”).
  • GitHub repository Data Visualization using Matplotlib, by Udacity.

Conclusion:

Because the human brain is not designed to process such a large amount of unstructured, raw data and turn it into something usable and understandable form, we require techniques to visualize data. We need graphs and charts to communicate data findings so that we can identify patterns and trends to gain insight and make better decisions faster. Jupyter Hub for Data Visualization using Python provides an in-browser coding environment with just a single click, hence providing ease of installation. Through our offer, a user can explore various application domains of data visualizations without worrying about the configuration and computations.

At Data Science Dojo, we deliver data science education, consulting, and technical services to increase the power of data. We are therefore adding a free Jupyter Notebook Environment dedicated specifically for Data Visualization using Python. The offering leverages the power of Microsoft Azure services to run effortlessly with outstanding responsiveness. Make your complex data understandable and insightful with us and Install the Jupyter Hub offer now from the Azure Marketplace by Data Science Dojo, your ideal companion in your journey to learn data science!

Try Now!

Use Python and BeautifulSoup to web scrape. Web scraping is a very powerful tool to learn for any data professional. Make the entire internet your database.

Web scraping tutorial

With web scraping, the entire internet becomes your database. In this tutorial, we show you how to parse a web page into a data file (csv) using a Python package called BeautifulSoup.

web scraping

There are many services out there that augment their business data or even build out their entire business by using web scraping. For example there is a steam sales website that tracks and ranks steam sales, updated hourly. Companies can also scrape product reviews from places like Amazon to stay up-to-date with what customers are saying about their products.


The code

from bs4 import BeautifulSoup as soup  # HTML data structure
from urllib.request import urlopen as uReq  # Web client
#URl to web scrap from.
#in this example we web scrap graphics cards from Newegg.com
page_url = "http://www.newegg.com/Product/ProductList.aspx?Submit=ENE&N=-1&IsNodeId=1&Description=GTX&bop=And&Page=1&PageSize=36&order=BESTMATCH"
#opens the connection and downloads html page from url
uClient = uReq(page_url)
#parses html into a soup data structure to traverse html
#as if it were a json data type.
page_soup = soup(uClient.read(), "html.parser")
uClient.close()
#finds each product from the store page
containers = page_soup.findAll("div", {"class": "item-container"})
#name the output file to write to local disk
out_filename = "graphics_cards.csv"
#header of csv file to be written
headers = "brand,product_name,shippingn"
#opens file, and writes headers
f = open(out_filename, "w")
f.write(headers)
#loops over each product and grabs attributes about
#each product
for container in containers:
# Finds all link tags "a" from within the first div.
make_rating_sp = container.div.select("a")
# Grabs the title from the image title attribute
# Then does proper casing using .title()
brand = make_rating_sp[0].img["title"].title()
# Grabs the text within the second "(a)" tag from within
# the list of queries.
product_name = container.div.select("a")[2].text
# Grabs the product shipping information by searching
# all lists with the class "price-ship".
# Then cleans the text of white space with strip()
# Cleans the strip of "Shipping $" if it exists to just get number
shipping = container.findAll("li", {"class": "price-ship"})[0].text.strip().replace("$", "").replace(" Shipping", "")
# prints the dataset to console
print("brand: " + brand + "n")
print("product_name: " + product_name + "n")
print("shipping: " + shipping + "n")
# writes the dataset to file
f.write(brand + ", " + product_name.replace(",", "|") + ", " + shipping + "n")
f.close()  # Close the file

The video (enjoy!)

For more info, there’s a script that does the same thing in R

Want to learn more data science techniques in Python? Take a look at this introduction to Python for Data Science

Syed Saad Peerzada
| July 17, 2022

Data Science Dojo has launched Jupyter Hub for Machine Learning using Python offering to the Azure Marketplace with pre-installed machine learning libraries and pre-cloned GitHub repositories of famous machine learning books which help the learner to take the first steps into the field of machine learning.

What is machine learning?

Machine learning is a sub-field of Artificial Intelligence. It is an innovative technology that allows machines to learn from historical data and provide the best results to predict outcomes.

Machine learning using Python

Machine learning requires exploratory data analysis, data processing, and the training of data to predict outcomes. Python provides a vast number of libraries and frameworks that let the user collect, analyze and transform data by just using built-in functions provided by the library which makes coding easy and also saves a significant amount of time.

machine learning python
Machine learning using Python

 PRO TIP: Join our 5-day instructor-led Python for Data Science training to enhance your machine learning skills.

Challenges for individuals

Individuals who are new to machine learning and want to excel in their path in machine learning usually lack computing as well as learning resources to gain hands-on experience with machine learning. A beginner in machine learning also faces compatibility issues while installing libraries.

What we provide

With just a single click, Jupyter Hub for Machine Learning using Python comes with pre-installed machine learning python libraries, which gives the learner an effortless coding environment in the Azure cloud and reduces the burden of installation. Moreover, this offer provides the learner with repositories of famous books on machine learning which contain chapter-wise notebooks which serve as a learning resource for a user in gaining hands-on experience with machine learning. The heavy computations required for Machine Learning applications are not performed on the user’s local machine. Instead, they are performed in the Azure cloud, which increases responsiveness and processing speed.

Listed below are the pre-installed machine learning python libraries and the sources of repositories of machine learning books provided by this offer:

Python libraries

  • Pandas
  • NumPy
  • scikit-learn
  • mlpack
  • matplotlib
  • SciPy
  • Theano
  • Pycaret
  • Orange3
  • seaborn

Repositories

  •  Github repository of book ‘Python Machine Learning Book 1st Edition’, by author Sebastian Raschka.
  •  Github repository of book ‘Python Machine Learning Book 2nd Edition’, by author Sebastian Raschka.
  •  Github repository of the book ‘Hands-on Machine Learning with Scikit Learn, Keras, and TensorFlow’, by author Geron-Aurelien.
  •  Github repository of ‘Microsoft Azure Cloud Advocates 12-week Machine Learning curriculum’.

Conclusion

Jupyter Hub for Machine Learning using Python provides an in-browser coding environment with just a single click, hence providing ease of installation. Through this offer, a user can work on a variety of machine learning applications including stock market trading, email spam and malware filtering, product recommendations, online customer support, medical diagnosis, online fraud detection, and image recognition.

Jupyter Hub for Machine Learning using Python offered by Data Science Dojo is ideal to learn more about machine learning without the need to worry about configurations and computing resources. The heavy resource requirement for processing and training large data for these applications is no longer an issue as data-intensive computations are now performed on Microsoft Azure which increases processing speed.

At Data Science Dojo, we deliver data science education, consulting, and technical services to increase the power of data. We are therefore adding a free Jupyter Notebook Environment dedicated specifically for Machine Learning using Python. The offering leverages the power of Microsoft Azure services to run effortlessly with outstanding responsiveness. Install the Jupyter Hub offer now from the Azure Marketplace by Data Science Dojo, your ideal companion in your journey to learn data science!

Try Now!

Ayesha Saleem
| July 18, 2022

Learning data analytics is a challenge for beginners. Take your learning experience of data analytics one step ahead with these nine data analytics books. Explore a range of topics, from big data to artificial intelligence.

Data analytics books
Books on Data Analytics

Data Analytics Books

1. Data Science for Business: What You Need to Know about Data Mining and Data-Analytic Thinking by Foster Provost and Tom Fawcett

This book is written by two globally esteemed data science experts who introduce their readers to the fundamental principles of data science and then dig deep into the important role data plays in business-related decision-making. They do a great job of demonstrating different techniques and ideas related to analytical thinking without getting into too many technicalities.

Through this book, you can not only begin to appreciate the importance of communication between business strategists and data scientists but can also discover how to approach business problems analytically to generate value.

2. The Data Science Design Manual (Texts in Computer Science) eBook: S. Skiena, Steven: Books

To survive in a data-driven world, we need to adopt the skills necessary to analyze datasets acquired. Data Science is critical to statistics, data visualization, machine learning, and mathematical modeling, Steven in this book give an overview of data science introduction for beginners in this emerging discipline.

The second part of the book highlights the essential skills, knowledge, and principles required to collect, analyze and interpret data. This book leaves learners spellbound with its step-by-step guidance to develop an inside-out theoretical and practical understanding of data science.

The Data Science Design Manual is a thorough instructor guide for learners eager to kick off their learning journey in Data Science. Lastly, Steven added the application of data science in the world, a wide range of exercises, Kaggle challenges, and most interestingly the examples from a data science show, The Quant Shop to excite the learners.

3. Data Analytics Made Accessible by Anil Maheshwari

Are you a data enthusiast looking to finally dip your toes in the field? Start with Data Analytics Made Accessible by Anil Maheshwari.  Get a sense of what data analytics is all about and how significant a role it plays in real-world scenarios with this informative, easy-to-follow read.

In fact, this book is considered such a vital resource that numerous universities across the globe have added it to their required textbooks list for their analytics courses. It sheds light on the relationship between business and data by talking at length about business intelligence, data mining, and data warehousing.

4. Python for Data Analysis by Wes McKinney

Written by the main author of the Pandas library, Python for Data Analysis is a book that spells out the basics of manipulating, processing, cleaning, and crunching data in Python. It is a hands-on book that walks its readers through a broad set of real-world case studies and enables them to solve different types of data analysis problems.

It introduces different data science tools in Python to the readers in order to get them started on loading, cleaning, transforming, merging, and reshaping data. It also walks you through creating informative visualizations using Matplotlib.

5. Big Data: A Revolution That Will Transform How We Live, Work, and Think by Viktor Mayer-Schönberger and Kenneth Cukier

This book is tailor-made for those who want to know the significance of data analytics across different industries. In this work, these two renowned domain experts bring the buzzword ‘big data’ under the limelight and try to dissect how it’s impacting our world and changing our lives, for better or for worse.

It does not delve into the technical aspects of data science algorithms or applications, rather it’s more of a theoretical primer on what big data really is and how it’s becoming central to different walks of life. Apart from encouraging the readers to embrace this ground-breaking technological development, it also reminds them of the potential digital hazards it poses and how we can protect ourselves from them.

6. Business Unintelligence: Insight and Innovation beyond Analytics and Big Data by Barry Devlin

This book is great for someone who is looking to read through the past, present, and future of business intelligence. Highlighting the great successes and overlooked weaknesses of traditional business intelligence processes, Dr. Devlin delves into how analytics and big data have transformed the landscape of modern-day business intelligence.

It identifies the tried-and-tested business intelligence practices and provides insights into how the trinity of information, people, and process conjoin to generate competitive advantage and drive business success in this rapidly advancing world. Furthermore, in this book, Dr. Delvin recommends several new models and frameworks that businesses and companies can employ for an even better tomorrow.

Join our Data Science Bootcamp today to start your career in the world of data.

7. Storytelling with Data: A Data Visualization Guide for Business Professionals by Cole Nussbaumer Knaflic

Globally, the culture is visual. Everything we consume from art, and advertisements to TV is visual. Data visualization is the art of narrating stories with a purpose. In this book, Knaflic highlights key points to effectively tell a story backed by data. The book journeys through the importance of situating your data story within a context, guides on the most suitable charts, graphs, and maps to spot trends and outliers, and discusses how to declutter and retain focus on the key points.

This book is a valuable addition for anyone eager to grasp the basic concepts of data communication. Once you finish reading the book, you will gain a general understanding of several graphs that add a spark to the stories you create from data. Knaflic instills in you the knowledge to tell a story with an impact.

Learn about lead generation through data analytics in this blog

10 ways data analytics can help you generate more leads



8. Developing Analytic Talent: Becoming a Data Scientist by Vincent Granville

Granville leveraged his lifetime’s experience of working with big data, business analytics, and predictive modeling to compose a “handbook” on data science and data scientists. In this book, you will find learnings that are rarely found in traditional statistical, programming, or computer science textbooks as the author writes from experiential knowledge rather than theoretical.

Moreover, this book covers all the most valuable information to help you excel in your career as a data scientist. It talks about how data science came to the fore in recent times and became indispensable for organizations using big data.

The book is divided into three components:

  • What is data science and how does it relate to other disciplines
  • Data science technical applications along with tutorials and case studies
  • Career resources for future and practicing data scientists

This data science book also helps decision-makers to build a better analytics team by informing them about specialized solutions and their uses. Lastly, if you plan to launch a startup around data science, giving this book a reader will give you an edge with some quick ideas based on 20+ industrial experience in Granville.

9. Learning R: A Step-By-Step Function Guide to Data Analysis by Richard Cotton

Non-technical users are scared off by programming languages. This book is an asset for all non-tech learners of the R language. The author compiled a list of tools that make access to statistical models much easier. This book, step-by-step, introduces the reader to R without digging into the details of statistics and data modeling.

The first part of this data science book introduces you to the basics of the R programming language. It discusses data structures, data environment, looping constructs, and packages. If you are already familiar with the basics you can begin with the second part of the book to learn the steps involved in data analysis like loading, cleaning, and transforming data. The second part of the book gives more insight to perform exploratory analysis and modeling.

10. Data Analytics: A Comprehensive Beginner’s Guide to Learn About the Realms of Data Analytics From A-Z by Benjamin Smith

Smith pens down the path to learning data analytics from A to Z in easy-to-understand language. The book offers simplified explanations for challenging topics like sophisticated algorithms, or even the Euclidean Square Estimate. At any point, while reading this book, you will not feel overwhelmed by technical jargon or menacing formulas.

First, quickly after introducing the topic, the author then explains a real-world use case and then brings forth the technical jargon. Smith demonstrates almost every practical topic with the use of Python, to enable learners to recreate the projects by themselves. The handy tips and practical exercises are a bonus.

11. Data Science and Big Data Analytics: Discovering, Analyzing, Visualizing, and Presenting Data by EMC Education Services

With the implementation of Big Data analytics, you explore greater avenues to investigate and generate authentic outcomes to support businesses. It instigates deeper insights that were previously not conveniently doable for everyone. Readers of Data Science and Big Data Analytics perform integration with real-time feeds and queries of structured and unstructured data. As you progress with the chapters in this book, you will open new paths to insight and innovation.

EMC Education Services in this book introduced some of the key techniques and tools suggested by the practitioners for Big Data analytics. Mastering the tools upholds an opportunity of becoming an active contributor to the challenging projects of Big Data analytics. This data science book consists of twelve chapters, crafting a reader’s journey from the Basics of Big Data analytics toward a range of advanced analytical methods, including classification, regression analysis, clustering time series, and text analysis.

All these lessons speak to assist multiple stakeholders which include business and data analysts looking to add Big Data analytics skills to their portfolio; database professionals and managers of business intelligence, analytics, or Big Data groups looking to enrich their analytic skills; and college graduates investigating data science as a career field

12. An Introduction to Statistical Methods and Data Analysis by Lyman Ott

Lyman Ott discussed the powerful techniques used in statistical analysis for both advanced undergraduate and graduate students. This book helps students with solutions to solve problems encountered in research projects. Not only does it greatly benefit students in decision making but it also allows them to become critical readers of statistical analyses. The book gained positive feedback from different levels of learners because it presumes the readers to have little or no mathematical background, thus explaining the complex topics in an easy-to-understand way.

Ott extensively covered the introductory statistics in the starting 11 chapters. The book also targets students who struggle to ace their undergraduate capstone courses. Lastly, it provides research studies and examples that connect the statistical concepts to data analysis problems.

Upgrade your data science skillset with our Python for Data Science training!

Ali Mohsin
| July 18, 2022

Data Science Dojo has launched  Jupyter Hub for Computer Vision using Python offering to the Azure Marketplace with pre-installed libraries and pre-cloned GitHub repositories of famous Computer Vision books and courses which enables the learner to run the example codes provided.

What is computer vision?

It is a field of artificial intelligence that enables machines to derive meaningful information from visual inputs.

Computer vision using Python

In the world of computer vision, Python is a mainstay. Even if you are a beginner or the language application you are reviewing was created by a beginner, it is straightforward to understand code. Because the majority of its code is extremely difficult, developers can devote more time to the areas that need it.



computer vision python
Computer vision using Python

Challenges for individuals

Individuals who want to understand digital images and want to start with it usually lack the resources to gain hands-on experience with Computer Vision. A beginner in Computer Vision also faces compatibility issues while installing libraries along with the following:

  1. Image noise and variability: Images can be noisy or low quality, which can make it difficult for algorithms to accurately interpret them.
  2. Scale and resolution: Objects in an image can be at different scales and resolutions, which can make it difficult for algorithms to recognize them.
  3. Occlusion and clutter: Objects in an image can be occluded or cluttered, which can make it difficult for algorithms to distinguish them.
  4. Illumination and lighting: Changes in lighting conditions can significantly affect the appearance of objects in an image, making it difficult for algorithms to recognize them.
  5. Viewpoint and pose: The orientation of objects in an image can vary, which can make it difficult for algorithms to recognize them.
  6. Occlusion and clutter: Objects in an image can be occluded or cluttered, which can make it difficult for algorithms to distinguish them.
  7. Background distractions: Background distractions can make it difficult for algorithms to focus on the relevant objects in an image.
  8. Real-time performance: Many applications require real-time performance, which can be a challenge for algorithms to achieve.



What we provide

Jupyter Hub for Computer Vision using the language solves all the challenges by providing you an effortless coding environment in the cloud with pre-installed computer vision python libraries which reduces the burden of installation and maintenance of tasks hence solving the compatibility issues for an individual.

Moreover, this offer provides the learner with repositories of famous books and courses on the subject which contain helpful notebooks which serve as a learning resource for a learner in gaining hands-on experience with it.

The heavy computations required for its applications are not performed on the learner’s local machine. Instead, they are performed in the Azure cloud, which increases responsiveness and processing speed.

Listed below are the pre-installed python libraries and the sources of repositories of Computer Vision books provided by this offer:

Python libraries

  • Numpy
  • Matplotlib
  • Pandas
  • Seaborn
  • OpenCV
  • Scikit Image
  • Simple CV
  • PyTorch
  • Torchvision
  • Pillow
  • Tesseract
  • Pytorchcv
  • Fastai
  • Keras
  • TensorFlow
  • Imutils
  • Albumentations

Repositories

  • GitHub repository of book Modern Computer Vision with PyTorch, by author V Kishore Ayyadevara and Yeshwanth Reddy.
  • GitHub repository of Computer Vision Nanodegree Program, by Udacity.
  • GitHub repository of book OpenCV 3 Computer Vision with Python Cookbook, by author Aleksandr Rybnikov.
  • GitHub repository of book Hands-On Computer Vision with TensorFlow 2, by authors Benjamin Planche and Eliot Andres.

Conclusion

Jupyter Hub for Computer Vision using Python provides an in-browser coding environment with just a single click, hence providing ease of installation. Through this offer, a learner can dive into the world of this industry to work with its various applications including automotive safety, self-driving cars, medical imaging, fraud detection, surveillance, intelligent video analytics, image segmentation, and code and character reader (or OCR).

Jupyter Hub for Computer Vision using Python offered by Data Science Dojo is ideal to learn more about the subject without the need to worry about configurations and computing resources. The heavy resource requirement to deal with large Images, and process and analyzes those images with its techniques is no more an issue as data-intensive computations are now performed on Microsoft Azure which increases processing speed.

At Data Science Dojo, we deliver data science education, consulting, and technical services to increase the power of data. We are therefore adding a free Jupyter Notebook Environment dedicated specifically for it using Python. Install the Jupyter Hub offer now from the Azure Marketplace, your ideal companion in your journey to learn data science!

Try Now!

Muhammad Taimoor
| June 17, 2022

This blog will cover how to build a recommendation system using Python libraries to perform web scrapping and carry out text transformation. It will teach you how to create your own dataset and further build a content-based recommendation system.

Introduction

recommendation system flowchart
A simple recommender system flow

The purpose of Data Science (DS) and Artificial Intelligence (AI) is to add value to a business by utilizing data and applying applicable programming skills. In recent years, Netflix, Amazon, Uber Eats, and other companies have made it possible for people to avail certain commodities with only a few clicks while sitting at home. However, in order to provide users with the most authentic experience possible, these platforms have developed recommendation systems that provide users with a variety of options based on their interests and preferences.

In general, recommendation systems are algorithms that curate data and provide consumers with appropriate material. There are three main types of recommendation engines

  1. Collaborative filtering: Collaborative filtering collects data regarding user behavior, activities, and preferences to predict what a person will like, based on their similarity to other users.
  1.  Content-based filtering: This algorithms analyze the possibility of objects being related to each other using statistics, and then offers possible outcomes to the user based on the highest probabilities.
  1. Hybrid of the two. In a hybrid recommendation engine, natural language processing tags can be generated for each product or item (movie, song), and vector equations are used to calculate the similarity of products.

Building a recommendation system using Python

In this blog, we will walk through the process of scraping a web page for data and using it to develop a recommendation system, using built-in python libraries. Scraping the website to extract useful data will be the first component of the blog. Moving on, text transformation will be performed to alter the extracted data and make it appropriate for our recommendation system to use.

Finally, our content-based recommender system will calculate the cosine similarity of each blog with the rest of the blogs and then suggest three comparable blogs for each blog post.

recommendation system steps
Flow for recommendation system using web scrapping

First step: Web scrapping

The purpose of going through the web scrapping process is to teach how to automate data entry for a recommender system. Knowing how to extract data from the internet will allow you to develop skills to create your own dataset using an entire webpage. Now, let us perform web scraping on the blogs page of online.datasciencedojo.com.

In this blog, we will extract relevant information to make up our dataset. From the first page, we will extract the URL, name, and description of each blog. By extracting the URL, we will have access to redirect our algorithm to each blog page and extract the name and description from the metadata.

The code below uses multiple python libraries and extracts all the URLs from the first page. In this case, it will return ten URLs. For building better concepts regarding web scrapping, I would suggest exploring and playing with these libraries to better understand their functionalities.

Note: The for loop is used to extract URLs from multiple pages.

import requests
import lxml.html
from lxml import objectify
from bs4 import BeautifulSoup
#List for storing urls
urls_final = []
#Extract the metadata of the page
for i in range(1):
url = 'https://online.datasciencedojo.com/blogs/?blogpage='+str(i)
reqs = requests.get(url)
soup = BeautifulSoup(reqs.text, 'lxml')
#Temporary lists for storing temporary data
urls_temp_1 = []
urls_temp_2=[]
temp=[]
#From the metadata, get the relevant information.
for h in soup.find_all('a'):
a = h.get('href')
urls_temp_1.append(a)
for i in urls_temp_1:
if i != None :
if 'blogs' in i:
if 'blogpage' in i:
None
else:
if 'auth' in i:
None
else:
urls_temp_2.append(i)
[temp.append(x) for x in urls_temp_2 if x not in temp]
for i in temp:
if i=='https://online.datasciencedojo.com/blogs/':
None
else:
urls_final.append(i)
print(urls_final)
Output
['https://online.datasciencedojo.com/blogs/regular-expresssion-101/',
'https://online.datasciencedojo.com/blogs/python-libraries-for-data-science/',
'https://online.datasciencedojo.com/blogs/shareable-data-quotes/',
'https://online.datasciencedojo.com/blogs/machine-learning-roadmap/',
'https://online.datasciencedojo.com/blogs/employee-retention-analytics/',
'https://online.datasciencedojo.com/blogs/jupyter-hub-cloud/',
'https://online.datasciencedojo.com/blogs/communication-data-visualization/',
'https://online.datasciencedojo.com/blogs/tracking-metrics-with-prometheus/',
'https://online.datasciencedojo.com/blogs/ai-webmaster-content-creators/',
'https://online.datasciencedojo.com/blogs/grafana-for-azure/']

Once we have the URLs, we move towards processing the metadata of each blog for extracting their name and description.

#Getting the name and description
name=[]
descrip_temp=[]
#Now use each url to get the metadata of each blog post
for j in urls_final:
url = j
response = requests.get(url)
soup = BeautifulSoup(response.text)
#Extract the name and description from each blog
metas = soup.find_all('meta')
name.append([ meta.attrs['content'] for meta in metas if 'property' in meta.attrs and meta.attrs['property'] == 'og:title' ])
descrip_temp.append([ meta.attrs['content'] for meta in metas if 'name' in meta.attrs and meta.attrs['name'] == 'description' ])
print(name[0])
print(descrip_temp[0])
Output:
['RegEx 101 - beginner’s guide to understand regular expressions']
['A regular expression is a sequence of characters that specifies a search pattern in a text. Learn more about Its common uses in this regex 101 guide.']

Second step: Text transformation

Similar to any task involving text, exploratory data analysis (EDA) is a fundamental part of any algorithm. In order to prepare data for our recommender system, data must be cleaned and transformed. For this purpose, we will be using built-in python libraries to remove stop words and transform data.

The code below uses the regex library to perform text transformation by removing punctuations, emojis, and more. Furthermore, we have imported a natural language toolkit (nlkt) to remove stop words.

Note: Stop words are a set of commonly used words in a language. Examples of stop words in English are “a”, “the”, “is”, “are” etc. They are so frequently used in the text that they hold a minimal amount of useful information.

import nltk
from nltk.corpus import stopwords
nltk.download("stopwords")
import re
#Removing stop words and cleaning data
stop_words = set(stopwords.words("english"))
descrip=[]
for i in descrip_temp:
for j in i:
text = re.sub("@\S+", "", j)
text = re.sub(r'[^\w\s]', '', text)
text = re.sub("\$", "", text)
text = re.sub("@\S+", "", text)
text = text.lower()
descrip.append(text)

Following this, we will be creating a bag of words. If you are not familiar with it, a bag of words is a representation of text that describes the occurrence of words within a document. It involves two things: A vocabulary of known words, and a measure of the presence of those words. For our data, it will represent all the keywords words in the dataset and calculate which words are used in each blog and the number of occurrences they have. The code below uses a built-in function to extract keywords.

from keras.preprocessing.text import Tokenizer
#Building BOW
model = Tokenizer()
model.fit_on_texts(descrip)
bow = model.texts_to_matrix(descrip, mode='count')
bow_keys=f'Key : {list(model.word_index.keys())}'

For building better concepts, here are all the extracted keywords.

"Key : ['data', 'analytics', 'science', 'hr', 'azure', 'use', 'analysis', 'dojo',
'launched', 'offering', 'marketplace', 'learn', 'libraries', 'article', 'machine', 'learning', 'work', 'trend', 'insights', 'step',
'help', 'set', 'content', 'creators', 'webmasters', 'regular', 'expression', 'sequence', 'characters', 'specifies', 'search', 'pattern',
'text', 'common', 'uses', 'regex', '101', 'guide', 'blog', 'covers', '6', 'famous', 'python', 'easy', 'extensive', 'documentation',
'perform', 'computations', 'faster', 'enlists', 'quotes', 'analogy', 'importance', 'adoption', 'wrangling', 'privacy', 'security', 'future',
'find', 'start', 'journey', 'kinds', 'projects', 'along', 'way', 'succeed', 'complex', 'field', 'classification', 'regression', 'tree',
'applied', 'companys', 'great', 'resignation', 'era', 'economic', 'triggered', 'covid19', 'pandemic', 'changed', 'relationship', 'offices',
'workers', 'explains', 'overcoming', 'refers', 'collection', 'employee', 'reporting', 'actionable', 'click', 'code', 'explanation', 'jupyter',
'hub', 'preinstalled', 'exploration', 'modeling', 'instead', 'loading', 'clients', 'bullet', 'points', 'longwinded', 'firms',
'visualization', 'tools', 'illustrate', 'message', 'prometheus', 'powerful', 'monitoring', 'alert', 'system', 'artificial', 'intelligence',
'added', 'ease', 'job', 'wonder', 'us', 'introducing', 'different', 'inventions', 'ai', 'helping', 'grafanas', 'harvest', 'leverages', 'power',
'microsoft', 'services', 'visualize', 'query', 'alerts', 'promoting', 'teamwork', 'transparency']"

The code below assigns each keyword an index value and calculates the frequency of each word being used per blog. When building a recommendation system, these keywords and their frequencies for each blog will act as the input. Based on similar keywords, our algorithm will link blog posts together into similar categories. In this case, we will have 10 blogs converted into rows and 139 keywords converted into columns.

import pandas as pd
#Creating df
df_name=pd.DataFrame(name)
df_name.rename(columns = {0:'Blog'}, inplace = True)
df_count=pd.DataFrame(bow)
frames=[df_name,df_count]
result=pd.concat(frames,axis=1)
result=result.set_index('Blog')
result=result.drop([0], axis=1)
for i in range(len(bow)):
result.rename(columns = {i+1:i}, inplace = True)
result
recommendation system input
Input for recommendation system

Third step: Cosine similarity

Whenever we are performing some tasks involving natural language processing and want to estimate the similarity between texts, we use some pre-defined metrics that are famous for providing numerical evaluations for this purpose. These metrics include:

  • Euclidean Distance
  • Cosine similarity
  • Jaccard similarity
  • Pearson similarity

While all four of them can be used to evaluate a similarity index between text documents, we will be using cosine similarity for our task. Cosine similarity, in data analysis, measures the similarity between two vectors of an inner product space. It is often used to measure document similarity in text analysis.It measures the cosine of the angle between two vectors and determines a numerical value indicating the probability of those vectors being in the same direction. The code alongside the heatmap shown below visualizes the cosine similarity index for all the blogs.

from sklearn.metrics.pairwise import cosine_similarity
import seaborn as sns
#Calculating cosine similarity
df_name=df_name.convert_dtypes(str)
temp_df=df_name['Blog']
sim_df = pd.DataFrame(cosine_similarity(result, dense_output=True))
for i in range(len(name)):
sim_df.rename(columns = {i:temp_df[i]},index={i:temp_df[i]}, inplace = True)
ax = sns.heatmap(sim_df)
recommendation system heatmap output
Recommendation System Heatmap Output

Fourth step: Evaluation

In the code below, our recommender system will extract the three most similar blogs for each blog using Pandas DataFrame.

Note: For each blog, the blog itself is also recommended because it was calculated to be the most similar blog, with the maximum cosine similarity index, 1.

content based recommendation system python ouput
Output for content-based recommendation System Python

Conclusion

This blog post covered a beginner’s method of building a recommendation system using python. While there are other methods to develop recommender systems, the first step is to outline the requirements of the task at hand. To learn more about this, experiment with the code and try to extract data from another web page or enroll in our Python for Data Science course and learn all the required concepts regarding Python fundamentals.

Full Code Available

Finding the top python packages and libraries that aren’t only popular, but get the job done isn’t easy. Here’s a list to help you out.

Out of all the Python scientific libraries and packages available, which ones are not only popular but the most useful in getting the job done?

Python packages and libraries

To help you filter down a list of libraries and packages worth adding to your data science toolbox, we have compiled our top picks for aspiring and practicing data scientists. But you’ll also want to know how to best use these tools for tricky, real-world data problems. So instead of leaving you with yet another top choice list among a quintillion lists, we explain how to make the most of these libraries using real-world examples.

You can learn more about how these packages fit into data science with Data Science Dojo’s introduction to Python course.

Data manipulation

Pandas

There’s a reason why pandas consistently tops published ranks on data science related libraries in Python. The library can help you with a variety of tasks, but it is particularly useful for data manipulation or data wrangling. It can save you a lot of leg work in not only your typical rudimentary data manipulation tasks, but in handling some pretty tricky problems you might encounter when slicing and filtering.

Multi-indexed data can be one of these tricky tasks. The library pandas takes care of advanced indexing, including multi-indexing, where you might need to work with higher-dimensional data or multiple index levels. For example, number of user interactions might be indexed by 1) product category, 2) time of day user interacted with the product, and 3) location of the user.

Instead of your typical table of rows and columns to represent the data, you might find it better to organize the number of user interactions into all cases that fall under x product category, with y time of day, and z location. This way you can easily see user interactions across each condition of product category, time of day, and user location. This saves you from having to apply a filter or group for all combinations of conditions in your traditional row-and-table structure.

Here is one way to multi-index data in pandas. With less than a few lines of code, pandas makes this easy to implement in Python:

import pandas as pd

data_multi_indx = table_data.set_index(['Product', 'Day of Week'])
print(data_multi_indx)
'''
Output:
                      Location  Num User Interactions
Product   Day of Week
Product 1 Morning            A                      3
          Morning            B                     90
          Morning            C                      7
          Afternoon          A                     17
          Afternoon          B                      1
          Afternoon          C                     82
Product 2 Morning            A                     27
          Morning            B                     70
          Morning            C                      3
          Afternoon          A                      1
          Afternoon          B                      1
          Afternoon          C                     98
Product 3 Morning            A                     94
          Morning            B                      5
          Morning            C                      1
          Afternoon          A                      0
          Afternoon          B                      7
          Afternoon          C                     93
'''

For the more rudimentary data manipulation tasks, pandas doesn’t require much effort on your part. You can simply use the functions available for imputing missing values, one-hot encoding, dropping columns and rows, and so on.

Here are a few example classes and functions in pandas that make rudimentary data manipulation easy in a few lines of code, at most.

For more lessons with Pandas, visit Data Independent.

Feature Description
fillna(value) Fill in missing values on a column or the whole data frame with a value such as the mean, median, or mode.
isna(data)/isnull(data) Check for missing values.
get_dummies(data_frame['Column']) Apply one-hot encoding on a column.
to_numeric(data_frame['Column']) Convert a column of values from strings to numeric values.
to_string(data_frame['Column']) Convert a column of values from numeric values to strings.
to_datetime(data_frame['Column']) Convert a column of datetimes in string format to standard datetime format.
drop(columns=['Column0','Column1']) Drop specific columns or useless columns in your data frame.
drop(data.frame.index[[rownum0,rownum1]]) Drop specific rows or useless rows in your data frame.

NumPy

Another library that keeps topping the ranks is numpy. This library can handle many tasks, but it is particularly useful when working with multi-dimensional arrays and performing calculations on these arrays. This can be tricky to do in more conventional ways, where you need to find the index of a value or certain values inside another index, with multiple indices.

This is where numpy shows its strength. Its array() function means standard arrays can be simply added and nicely bundled into a multi-dimensional array. Calculations on these arrays can also be easily implemented using numpy’s vast array (pun intended) of mathematical functions.

Let’s picture an example where numpy’s multi-dimensional arrays are useful. A company tracks or records if a user was/was not shown a mobile product in the morning, afternoon, and night, delivered through a mobile notification. Based on the level of user interaction with the shown product, the company also records a user engagement score.

Data points on each user’s shown product and engagement score are stored inside an array; each array stores these values for each user. The company would like to quickly and simply bundle all user arrays.

In addition to this, using engagement score and purchase history, the company would like to calculate and identify the minimum distance (or difference) across all users’ data points so that users who follow a similar pattern can be categorized and targeted accordingly.

numpy’s array() makes it easy to bundle user arrays into a multi-dimensional array and argmin() and linalg.norm() find the min Euclidean distance between users, as an example of the kinds of calculations that can be done on a multi-dimensional array:

import numpy as np

# Records tracking whether user was/was not shown product during
# morning, afternoon, and night, and user engagement score
user_0 = [0,0,1,0.7]
user_1 = [0,1,0,0.4]
user_2 = [1,0,0,0.0]
user_3 = [0,0,1,0.9]
user_4 = [0,1,0,0.3]
user_5 = [1,0,0,0.0]
# Create a multi-dimensional array to bundle all users
# Can use arrays with mixed data types by specifying
# the object data type in numpy multi-dimensional arrays
users_multi_dim = np.array([user_0,user_1,user_2,user_3,user_4,user_5],dtype=object)
print(users_multi_dim)
'''
Output:
[[0 0 1 0.7]
 [0 1 0 0.4]
 [1 0 0 0.0]
 [0 0 1 0.9]
 [0 1 0 0.3]
 [1 0 0 0.0]]
'''
# To view which user was/was not shown the product
# either morning, afternoon or night, pandas easily
# allows you to index and label the data
row_names = [_ for _ in ['User 0','User 1','User 2','User 3','User 4','User 5']]
col_names = [_ for _ in ['Product Shown Morning','Product Shown Afternoon',
                         'Product Shown Night','User Engagement Score']]
users_df_indexed = pd.DataFrame(users_multi_dim,index=row_names,columns=col_names)
print(users_df_indexed)
'''
Output:
       Product Shown Morning Product Shown Afternoon Product Shown Night User Engagement Score
User 0                     0                       0                   1                   0.7
User 1                     0                       1                   0                   0.4
User 2                     1                       0                   0                     0
User 3                     0                       0                   1                   0.9
User 4                     0                       1                   0                   0.3
User 5                     1                       0                   0                     0
'''
# Find which existing user is closest to the engagement
# and purchase behavior of a new user by calculating the
# min Euclidean distance on a numpy multi-dimensional array
user_0 = [0.7,51.90,2]
user_1 = [0.4,25.95,1]
user_2 = [0.0,0.00,0]
user_3 = [0.9,77.85,3]
user_4 = [0.3,25.95,1]
user_5 = [0.0,0.00,0]
users_multi_dim = np.array([user_0,user_1,user_2,user_3,user_4,user_5])
new_user = np.array([0.8,77.85,3])
closest_to_new = np.argmin(np.linalg.norm(users_multi_dim-new_user,axis=1))
print('User', closest_to_new, 'is closest to the new user')
'''
Output:
User 3 is closest to the new user
'''

Data modeling

Statsmodels

The main strength of statsmodels is its focus on statistics, going beyond the ‘machine learning out-of-the-box’ approach. This makes it a popular choice for data scientists. Conducting statistical tests to find significantly different variables, checking for normality in your data, checking the standard errors, and so on, cannot be underestimated when trying to build the most effective model you can build. Your model is only as good as your inputs, and statsmodels is designed to help you better understand and customize your inputs.

The library also covers an exhaustive list of predictive models to choose from, depending on your predictors and outcome variable(s). It covers your classic Linear Regression models (including ordinary least squares, weighted least squares, recursive least squares, and more), Generalized Linear models, Linear Mixed Effects models, Binomial and Poisson Bayesian models, Logit and Probit models, Time Series models (including autoregressive integrated moving average, dynamic factor, unobserved component,and more), Hidden Markov models, Principal Components and other techniques for Multivariate models, Kernel Density estimators, and lots more.

Here are the classes and functions in statsmodels that cover the main modeling techniques useful for many prediction tasks.

Classes and functions in statsmodel - Python packages

Scikit-learn

Any library that makes machine learning more accessible and easier to implement is bound to make the top choice list among aspiring and practicing data scientists. The library scikit-learn not only allows models to be easily implemented out-of-the-box but also offers some auto fine tuning.

Finding the best possible combination of model parameters is a key example of fine tuning. The library offers a few good ways to search for the optimal set of parameters, given the algorithm and problem to solve. The grid search and random search algorithms in scikit-learn evaluate different combinations of parameters until they find the best combo that results in the best outcome, or a better performing model.

The grid search goes through every possible combination, whereas the random search randomly samples the parameters over a fixed number of times/iterations. Cross validating your model on many subsets of data is also easy to implement using scikit-learn. With this kind of automation, the library offers data scientists a massive time saver when building models.

The library also covers all the essential machine learning models from classification (including Support Vector Machine, Random Forest, etc), to regression (including Ridge Regression, Lasso Regression, etc), and clustering (including k-Means, Mean Shift, etc).

Here are the classes and functions in scikit-learn that cover the main modeling techniques useful for many prediction tasks.

Feature Description
SVC()GaussianNB()LogisticRegression()DecisionTreeClassifier(),

RandomForestClassifier()SGDClassifier()MLPClassifier()

Classification models: Support Vector Machine, Gaussian Naïve Bayes, Logistic Regression, Decision Tree, Random Forest, Stochastic Gradient Descent, Multi-Layer Perceptron
linear_model.Ridge()linear_model.Lasso()SVR()DecisionTreeRegressor(),

RandomForestRegressor()SGDRegressorMLPRegressor()

Regression models: Ridge Regression, Lasso Regression, Support Vector Machine, Decision Tree, Random Forest, Stochastic Gradient Descent, Multi-Layer Perceptron
KMeans()AffinityPropagation()MeanShift()AgglomerativeClustering Clustering models: k-Means, Affinity Propagation, Mean Shift, Agglomerative Hierarchical Clustering

Data visualization

Plotly

The libraries matplotlib and seaborn will easily take care of your basic static plot functions, which are important for your own internal exploration or understanding of the data. But when presenting visual insights to business folks or users, interactivity is where we are headed these days.

Using JavaScript functionality, plotly renders interactive graphs in the form of zooming in and panning out of the graph panel, hovering over objects for more information, and dragging objects into position to further explore relationships in the data. Graphs can be customized to your heart’s content.

Here are just a few of many tricks that plotly offers:

Feature Description
hovermodehoverinfo Controls the mode and text when a user hovers over an object.
on_selection()on_click() Allows a user to select or click on an object and have that selected object change color, for example.
update Modifies a graph’s layout and data such as titles and annotations.
animate Creates an animated graph.

Bokeh

Much like plotlybokeh also offers interactive graphs. But one feature that stands out in bokeh is linked interactions. This is useful when keeping separate graphs in unison, where the user interacts with one graph and needs to compare with the other while they are in sync. For example, a user zooms into a graph, effectively changing the range of the graph, and then would like to compare with the second graph. The second graph would need to automatically update its range so that both graphs can be easily compared like-for-like.

Here are some key tricks that bokeh offers:

Feature Description
figure() Creates a new plot and allows linking to the range of another plot.
HoverTool()hover_glyph Allows user to hover over an object for more information.
selection_glyph Selects a particular glyph object for styling.
Slider() Creates a slider to dynamically update the plot based on the slide range.
Rahim Rasool
| May 22, 2019

There is so much to explore when it comes to spatial visualization using Python’s Folium library.

Spatial visualization

For problems related to crime mapping, housing prices or travel route optimization, spatial visualization could be the most resourceful tool in getting a glimpse of how the instances are geographically located. This is beneficial as we are getting massive amounts of data from several sources such as cellphones, smartwatches, trackers, etc. In this case, patterns and correlations, which otherwise might go unrecognized, can be extracted visually.

This blog will attempt to show you the potential of spatial visualization using the Folium library with Python. This tutorial will give you insights into the most important visualization tools that are extremely useful while analyzing spatial data.

Introduction to folium

Folium is an incredible library that allows you to build Leaflet maps. Using latitude and longitude points, Folium can allow you to create a map of any location in the world. Furthermore, Folium creates interactive maps that may allow you to zoom in and out after the map is rendered.

We’ll get some hands-on practice with building a few maps using the Seattle Real-time Fire 911 calls dataset. This dataset provides Seattle Fire Department 911 dispatches, and every instance of this dataset provides information about the address, location, date/time and type of emergency of a particular incident. It’s extensive and we’ll limit the dataset to a few emergency types for the purpose of explanation.

Let’s begin

Folium can be downloaded using the following commands.

Using pip:

$ pip install folium

Using conda:

$ conda install -c conda-forge folium

Start by importing the required libraries.

import pandas as pd
import numpy as np
import folium

Let us now create an object named ‘seattle_map’ which is defined as a folium.Map object. We can add other folium objects on top of the folium.Map to improve the map rendered. The map has been centered to the longitude and latitude points in the location parameters. The zoom parameter sets the magnification level for the map that’s going to be rendered. Moreover, we have also set the tiles parameter to ‘OpenStreetMap’ which is the default tile for this parameter. You can explore more tiles such as StamenTerrain or Mapbox Control in Folium‘s documentation.

seattle_map = folium. Map
(location = [47.6062, -122.3321],
tiles = 'OpenStreetMap',
 zoom_start = 11)
seattle_map
Geospatial visualization of Seattle map
Seattle map centered to the longitude and latitude points in the location parameters.

We can observe the map rendered above. Let’s create another map object with a different tile and zoom_level. Through ‘Stamen Terrain’ tile, we can visualize the terrain data which can be used for several important applications.

We’ve also inserted a folium. Marker to our ‘seattle_map2’ map object below. The marker can be placed to any location specified in the square brackets. The string mentioned in the popup parameter will be displayed once the marker is clicked as shown below.

seattle_map2 = folium. Map
(location=[47.6062, -122.3321],
    tiles = 'Stamen Terrain',
    zoom_start = 10)
#inserting marker
folium.Marker(
    [47.6740, -122.1215],
    popup = 'Redmond'
).add_to(seattle_map2)
seattle_map2
Folium Seattle map
Folium marker inserted into Seattle map

We are interested to use the Seattle 911 calls dataset to visualize the 911 calls in the year 2019 only. We are also limiting the emergency types to 3 specific emergencies that took place during this time.

We will now import our dataset which is available through this link (in CSV format). The dataset is huge, therefore, we’ll only import the first 10,000 rows using pandas read_csv method. We’ll use the head method to display the first 5 rows.

(This process will take some time because the data-set is huge. Alternatively, you can download it to your local machine and then insert the file path below)

path = "https://data.seattle.gov/api/views/kzjm-xkqj/rows.csv?accessType=DOWNLOAD"
seattle911 = pd.read_csv(path, nrows = 10000)
seattle911.head()
Imported dataset of Seattle
Seattle dataset for visualization with longitude and latitude

Using the code below, we’ll convert the datatype of our Datetime variable to Date-time format and extract the year, removing all other instances that occurred before 2019.

seattle911['Datetime'] = pd.to_datetime(seattle911['Datetime'],
                                        format='%m/%d/%Y %H:%M', utc=True)
seattle911['Year'] = pd.DatetimeIndex(seattle911['Datetime']).year
seattle911 = seattle911[seattle911.Year == 2019]

We’ll now limit the Emergency type to ‘Aid Response Yellow’, ‘Auto Fire Alarm’ and ‘MVI – Motor Vehicle Incident’. The remaining instances will be removed from the ‘seattle911’ dataframe.

seattle911 = seattle911[seattle911.Type.isin(['Aid Response Yellow',
                                              'Auto Fire Alarm',
                                              'MVI - Motor Vehicle Incident'])]

We’ll remove any instance that has a missing longitude or latitude coordinate. Without these values, the particular instance cannot be visualized and will cause an error while rendering.

#drop rows with missing latitude/longitude values
seattle911.dropna(subset = ['Longitude', 'Latitude'], inplace = True)

seattle911.head()

geospatial visualization python tutorial | Data Science Dojo

Now let’s step towards the most interesting part. We’ll map all the instances onto the map object we created above, ‘seattle_map’. Using the code below, we’ll loop over all our instances up to the length of the dataframe. Following this, we will create a folium.CircleMarker (which is similar to the folium.Marker we added above). We’ll assign the latitude and longitude coordinates to the location parameter for each instance. The radius of the circle has been assigned to 3, whereas the popup will display the address of the particular instance.

As you can notice, the color of the circle depends on the emergency type. We will now render our map.

for i in range(len(seattle911)):

    folium.CircleMarker( location = [seattle911.Latitude.iloc[i], seattle911.Longitude.iloc[i]],
        radius = 3,
        popup = seattle911.Address.iloc[i],
        color = '#3186cc' if seattle911.Type.iloc[i] == 'Aid Response Yellow' else '#6ccc31'
        if seattle911.Type.iloc[i] =='Auto Fire Alarm' else '#ac31cc',).add_to(seattle_map)
seattle_map
Seattle emergency map
The map gives us insights about where the emergency takes place across Seattle during 2019
Voila! The map above gives us insights about where and what emergency took place across Seattle during 2019. This can be extremely helpful for the local government to more efficiently place its emergency combating resources.

Advanced features provided by folium

Let us now move towards slightly advanced features provided by Folium. For this, we will use the National Obesity by State dataset which is also hosted on data.gov. There are 2 types of files we’ll be using, a csv file containing the list of all states and the percentage of obesity in each state, and a geojson file (based on JSON) that contains geographical features in form of polygons.

Before using our dataset, we’ll create a new folium.map object with location parameters including coordinates to center the US on the map, whereas, we’ve set the ‘zoom_start’ level to 4 to visualize all the states.

usa_map = folium.Map(
    location=[37.0902, -95.7129],
    tiles = 'Mapbox Bright',
    zoom_start = 4)
usa_map
USA map
Location parameters with US on the map

We will assign the URLs of our datasets to ‘obesity_link’ and ‘state_boundaries’ variables, respectively.

obesity_link = 'http://data-lakecountyil.opendata.arcgis.com/datasets/3e0c1eb04e5c48b3be9040b0589d3ccf_8.csv'
state_boundaries = 'http://data-lakecountyil.opendata.arcgis.com/datasets/3e0c1eb04e5c48b3be9040b0589d3ccf_8.geojson'

We will use the ‘state_boundaries’ file to visualize the boundaries and areas covered by each state on our folium.Map object. This is an overlay on our original map and similarly, we can visualize multiple layers on the same map. This overlay will assist us in creating our choropleth map that is discussed ahead.

folium.GeoJson(state_boundaries).add_to(usa_map)
usa_map
USA map
USA map with state boundaries

The ‘obesity_data’ dataframe can be viewed below. It contains 5 variables. However, for the purpose of this demonstration, we are only concerned with the ‘NAME’ and ‘Obesity’ attributes.

obesity_data = pd.read_csv(obesity_link)
obesity_data.head()

Obesity data frame (Geospatial analysis)

Choropleth map

Now comes the most interesting part! Creating a choropleth map. We’ll bind the ‘obesity_data’ data frame with our ‘state_boundaries’ geojson file. We have assigned both the data files to our variables ‘data’ and ‘geo_data’ respectively. The columns parameter indicates which DataFrame columns to use, whereas, the key_on parameter indicates the layer in the GeoJSON on which to key the data.

We have additionally specified several other parameters that will define the color scheme we’re going to use. Colors are generated from Color Brewer’s sequential palettes.

By default, linear binning is used between the min and the max of the values. Custom binning can be achieved with the bins parameter.

folium. Choropleth( geo_data = state_boundaries,
    name = 'choropleth',
    data = obesity_data,
    columns = ['NAME', 'Obesity'],
    key_on = 'feature.properties.NAME',
    fill_color = 'YlOrRd',
    fill_opacity = 0.9,
    line_opacity = 0.5,
    legend_name = 'Obesity Percentage').add_to(usa_map)
folium.LayerControl().add_to(usa_map)
usa_map

Choropleth map using folium function

Awesome! We’ve been able to create a choropleth map using a simple set of functions offered by Folium. We can visualize the obesity pattern geographically and uncover patterns not visible before. It also helped us in gaining clarity about the data, more than just simplifying the data itself.

You might now feel powerful enough after attaining the skill to visualize spatial data effectively. Go ahead and explore Folium‘s documentation to discover the incredible capabilities that this open-source library has to offer.

Thanks for reading! If you want more datasets to play with, check out this blog post. It consists of 30 free datasets with questions for you to solve.

References:

In the second article of this chatbot series, learn how to build a rule-based chatbot and discuss the business applications of them.

Chatbots have become extremely popular in recent years and their use in the industry has skyrocketed. They have found a strong foothold in almost every task that requires text-based public dealing. They have become so critical in the support industry, for example, that almost 25% of all customer service operations are expected to use them by 2020.

In the first part of A Beginners Guide to Chatbotswe discussed what chatbots were, their rise to popularity and their use-cases in the industry. We also saw how the technology has evolved over the past 50 years.

In this second part of the series, we’ll be taking you through how to build a simple Rule-based chatbot in Python. Before we start with the tutorial, we need to understand the different types of chatbots and how they work.

Types of chatbots

Chatbots can be classified into two different types, based on how they are built:

Rule-based Chatbots

Rule-based chatbots are pretty straight forward. They are provided with a database of responses and are given a set of rules that help them match out an appropriate response from the provided database. They cannot generate their own answers but with an extensive database of answers and smartly designed rules, they can be very productive and useful.

The simplest form of Rule-based Chatbots have one-to-one tables of inputs and their responses. These bots are extremely limited and can only respond to queries if they are an exact match with the inputs defined in their database.

AI-based chatbots

With the rise in the use of machine learning in recent years, a new approach to building chatbots has emerged. Using artificial intelligence, it has become possible to create extremely intuitive and precise chatbots tailored to specific purposes.

Unlike their rule-based kin, AI based chatbots are based on complex machine learning models that enable them to self-learn.

Now that we’re familiar with how chatbots work, we’ll be looking at the libraries that will be used to build our simple Rule-based Chatbot.

Natural Language Toolkit (NLTK)

Natural Language Toolkit is a Python library that makes it easy to process human language data. It provides easy-to-use interfaces to many language-based resources such as the Open Multilingual Wordnet, as well as access to a variety of text-processing libraries.

Regular Expression (RegEx) in Python

regular expression is a special sequence of characters that helps you search for and find patterns of words/sentences/sequence of letters in sets of strings, using a specialized syntax. They are widely used for text searching and matching in UNIX.

Python includes support for regular expression through the re package.

Want to upgrade your Python abilities? Checkout Data Science Dojo’s Introduction to Python for Data Science.

Building a chatbot

This very simple rule based chatbot will work by searching for specific keywords in inputs given by a user. The keywords will be used to understand what action the user wants to take (user’s intent). Once the intent is identified, the bot will then pick out a response appropriate to the intent.



Keyword intent

The list of keywords the bot will be searching for and the dictionary of responses will be built up manually based on the specific use case for the chatbot.

We’ll be designing a very simple chatbot for a Bank. The bot will be able to respond to greetings (Hi, Hello etc.) and will be able to answer questions about the bank’s hours of operation.

A flow of how the chatbot would process inputs is shown below;



Python chatbot process
Flow of how the chatbot will process

We will be following the steps below to build our chatbot

  1. Importing Dependencies
  2. Building the Keyword List
  3. Building a dictionary of Intents
  4. Defining a dictionary of responses
  5. Matching Intents and Generating Responses

Importing dependencies

The first thing we’ll need to do is import the packages/libraries we’ll be using. re is the package that handles regular expression in Python. We’ll also be using WordNet from NLTK. WordNet is a lexical database that defines semantical relationships between words. We’ll be using WordNet to build up a dictionary of synonyms to our keywords. This will help us expand our list of keywords without manually having to introduce every possible word a user could use.

# Importing modules
import re
from nltk.corpus import wordnet

Building a list of keywords

Once we have imported our libraries, we’ll need to build up a list of keywords that our chatbot will look for. This list can be as exhaustive as you want. The more keywords you have, the better your chatbot will perform.

As discussed previously, we’ll be using WordNet to build up a dictionary of synonyms to our keywords. For details about how WordNet is structured, visit their website.

Code:

# Building a list of Keywords
list_words=['hello','timings']
list_syn={}
for word in list_words:
    synonyms=[]
    for syn in wordnet.synsets(word):
        for lem in syn.lemmas():
            # Remove any special characters from synonym strings
            lem_name = re.sub('[^a-zA-Z0-9 \n\.]', ' ', lem.name())
            synonyms.append(lem_name)
    list_syn[word]=set(synonyms)
print (list_syn)

Output:

hello
{'hello', 'howdy', 'hi', 'hullo', 'how do you do'}
timings
{'time', 'clock', 'timing'}

Here, we first defined a list of words list_words that we will be using as our keywords. We used WordNet to expand our initial list with synonyms of the keywords. This list of keywords is stored in list_syn.

New keywords can simply be added to list_words. The chatbot will automatically pull their synonyms and add them to the keywords dictionary. You can also edit list_syn directly if you want to add specific words or phrases that you know your users will use.

Building a dictionary of intents

Once our keywords list is complete, we need to build up a dictionary that matches our keywords to intents. We also need to reformat the keywords in a special syntax that makes them visible to Regular Expression’s search function.

Code:

# Building dictionary of Intents & Keywords
keywords={}
keywords_dict={}
# Defining a new key in the keywords dictionary
keywords['greet']=[]
# Populating the values in the keywords dictionary with synonyms of keywords formatted with RegEx metacharacters
for synonym in list(list_syn['hello']):
    keywords['greet'].append('.*\\b'+synonym+'\\b.*')

# Defining a new key in the keywords dictionary
keywords['timings']=[]
# Populating the values in the keywords dictionary with synonyms of keywords formatted with RegEx metacharacters
for synonym in list(list_syn['timings']):
    keywords['timings'].append('.*\\b'+synonym+'\\b.*')
for intent, keys in keywords.items():
    # Joining the values in the keywords dictionary with the OR (|) operator updating them in keywords_dict dictionary
    keywords_dict[intent]=re.compile('|'.join(keys))
print (keywords_dict)

Output:

{'greet': re.compile('.*\\bhello\\b.*|.*\\bhowdy\\b.*|.*\\bhi\\b.*|.*\\bhullo\\b.*|.*\\bhow-do-you-do\\b.*'), 'timings': re.compile('.*\\btime\\b.*|.*\\bclock\\b.*|.*\\btiming\\b.*')}

The updated and formatted dictionary is stored in keywords_dict. The intent is the key and the string of keywords is the value of the dictionary.

Let’s look at one key-value pair of the keywords_dict dictionary to understand the syntax of Regular Expression;

{'greet': re.compile('.*\\bhullo\\b.*|.*\\bhow-do-you-do\\b.*|.*\\bhowdy\\b.*|.*\\bhello\\b.*|.*\\bhi\\b.*')

Regular Expression uses specific patterns of special Meta-Characters to search for strings or sets of strings in an expression.

Since we need our chatbot to search for specific words in larger input strings we use the following sequences of meta-characters:

.*\\bhullo\\b.*

In this specific sequence, the keyword (hullo) is encased between a \b sequence. This tells the RegEx Search function that the search parameter is the keyword (hullo).

The first sequence \bhullo\b is encased between a period-star .* sequence. This sequence tells the RegEx Search function to search the entire input string from beginning to end for the search parameter (hullo).

In the dictionary, multiple such sequences are separated by the OR | operator. This operator tells the search function to look for any of the mentioned keywords in the input string.

More details about Regular Expression and its syntax can be found here.

You can add as many key-value pairs to the dictionary as you want to increase the functionality of the chatbot.

Defining responses

The next step is defining responses for each intent type. This part is very straightforward. The responses are described in another dictionary with the intent being the key.

We’ve also added a fallback intent and its response. This is a fail-safe response in case the chatbot is unable to extract any relevant keywords from the user input.

Code:

# Building a dictionary of responses
responses={
    'greet':'Hello! How can I help you?',
    'timings':'We are open from 9AM to 5PM, Monday to Friday. We are closed on weekends and public holidays.',
    'fallback':'I dont quite understand. Could you repeat that?',
}

Matching intents and generating responses

Now that we have the back-end of the chatbot completed, we’ll move on to taking input from the user and searching the input string for our keywords.

We use the RegEx Search function to search the user input for keywords stored in the value field of the keywords_dict dictionary.  If you recall, the values in the keywords_dict dictionary were formatted with special sequences of meta-characters. RegEx’s search function uses those sequences to compare the patterns of characters in the keywords with patterns of characters in the input string.

If a match is found, the current intent gets selected and is used as the key to the responses dictionary to select the correct response.

Code:

print ("Welcome to MyBank. How may I help you?")
# While loop to run the chatbot indefinetely
while (True):
    # Takes the user input and converts all characters to lowercase
    user_input = input().lower()
    # Defining the Chatbot's exit condition
    if user_input == 'quit':
        print ("Thank you for visiting.")
        break
    matched_intent = None
    for intent,pattern in keywords_dict.items():
        # Using the regular expression search function to look for keywords in user input
        if re.search(pattern, user_input):
            # if a keyword matches, select the corresponding intent from the keywords_dict dictionary
            matched_intent=intent
    # The fallback intent is selected by default
    key='fallback'
    if matched_intent in responses:
        # If a keyword matches, the fallback intent is replaced by the matched intent as the key for the responses dictionary
        key = matched_intent
    # The chatbot prints the response that matches the selected intent
    print (responses[key])

The chatbot picked the greeting from the first user input (‘Hi’) and responded according to the matched intent. The same happened when it located the word (‘time’) in the second user input. The third user input (‘How can I open a bank account’) didn’t have any keywords that present in Bankbot’s database and so it went to its fallback intent.

You can add as many keywords/phrases/sentences and intents as you want to make sure your chatbot is robust when talking to an actual human.

Conclusion

This blog was a hands-on introduction to building a very simple rule-based chatbot in python. We only worked with 2 intents in this tutorial for simplicity. You can easily expand the functionality of this chatbot by adding more keywords, intents and responses.

As we saw, building a rule-based chatbot is a laborious process. In a business environment, a chatbot could be required to have a lot more intent depending on the tasks it is supposed to undertake.

In such a situation, rule-based chatbots become very impractical as maintaining a rule base would become extremely complex. In addition, the chatbot would severely be limited in terms of its conversational capabilities as it is near impossible to describe exactly how a user will interact with the bot.

AI-based Chatbots are a much more practical solution for real-world scenarios. In the next blog in the series, we’ll be looking at how to build a simple AI-based Chatbot in Python.

Do you want to learn more about machine learning and it’s applications? Check out Data Science Dojo’s online data science certificate program!

Usman Shahid
| June 10, 2020

Learn how to use Chatterbot, the Python library, to build and train AI-based chatbots.

Chatbots have become extremely popular in recent years and their use in the industry has skyrocketed. The chatbot market is projected to grow from $2.6 billion in 2019 to $9.4 billion by 2024. This doesn’t come as a surprise when you look at the immense benefits chatbots bring to businesses. According to a study by IBM, chatbots can reduce customer services cost by up to 30%.

In the third blog of A Beginners Guide to Chatbots, we’ll be taking you through how to build a simple AI-based chatbot with Chatterbot; a Python library for building chatbots.

Introduction to chatterbot

Chatterbot is a python-based library that makes it easy to build AI-based chatbots. The library uses machine learning to learn from conversation datasets and generate responses to user inputs. The library allows developers to train their chatbot instances with pre-provided language datasets as well as build their datasets.

Training chatterbot

A newly initialized Chatterbot instance starts with no knowledge of how to communicate. To allow it to properly respond to user inputs, the instance needs to be trained to understand how conversations flow. Since conversational chatbot Python relies on machine learning at its backend, it can very easily be taught conversations by providing it with datasets of conversations.

Chatterbot’s training process works by loading example conversations from provided datasets into its database. The bot uses the information to build a knowledge graph of known input statements and their probable responses. This graph is constantly improved and upgraded as the chatbot is used.

Chatterbot knowledge graph - AI based chatbot Python

Chatterbot knowledge graph (Source: Chatterbot Knowledgebase)

Chatterbot corpus

The Chatterbot Corpus is an open-source user-built project that contains conversational datasets on a variety of topics in 22 languages. These datasets are perfect for training a chatbot on the nuances of languages – such as all the different ways a user could greet the bot. This means that developers can jump right to training the chatbot on their customer data without having to spend time teaching common greetings.

Chatterbot has built-in functions to download and use datasets from the Chatterbot Corpus for initial training.

Chatterbot logic adapters

Conversational chatbot Python uses Logic Adapters to determine the logic for how a response to a given input statement is selected.

A typical logic adapter designed to return a response to an input statement will use two main steps to do this. The first step involves searching the database for a known statement that matches or closely matches the input statement. Once a match is selected, the second step involves selecting a known response to the selected match. Frequently, there will be several existing statements that are responses to the known match. In such situations, the Logic Adapter will select a response randomly. If more than one Logic Adapter is used, the response with the highest cumulative confidence score from all Logic Adapters will be selected.

logic adapters in chatbot
Working process of logic adapters- How logic adapters work (Source: Chatterbot Knowledgebase)

Chatterbot storage adapters

Chatterbot stores its knowledge graph and user conversation data in an SQLite database. Developers can interface with this database using Chatterbot’s Storage Adapters.

Storage Adapters allow developers to change the default database from SQLite to MongoDB or any other database supported by the SQLAlchemy ORM. Developers can also use these Adapters to add, remove, search, and modify user statements and responses in the Knowledge Graph as well as create, modify and query other databases that Chatterbot might use.

Building an AI-based chatbot

In this tutorial, we will be using the Chatterbot Python library to build an AI-based Chatbot.

We will be following the steps below to build our chatbot

  1. Importing Dependencies
  2. Instantiating a ChatBot Instance
  3. Training on Chatbot-Corpus Data
  4. Training on Custom Data
  5. Building a front end

Importing dependencies

The first thing we’ll need to do is import the modules we’ll be using. The ChatBot module contains the fundamental Chatbot class that will be used to instantiate our chatbot object. The ListTrainer module allows us to train our chatbot on a custom list of statements that we will define. The ChatterBotCorpusTrainer module contains code to download and train our chatbot on datasets part of the ChatterBot Corpus Project.

#Importing modules
from chatterbot import ChatBot
from chatterbot.trainers import ListTrainer
from chatterbot.trainers import ChatterBotCorpusTrainer

Instantiating chatbots instance

A chatbot instance can be created by creating a Chatbot object. The Chatbot object needs to have the name of the chatbot and must reference any logic or storage adapters you might want to use.

In the case you don’t want your chatbot to learn from user inputs after it has been trained, you can set the read-only parameter to True.

BankBot = ChatBot(name = 'BankBot',
                  read_only = False,
                  logic_adapters = ["chatterbot.logic.BestMatch"],
                  storage_adapter = "chatterbot.storage.SQLStorageAdapter")

Training on chatterbot-corpus data

Training your chatbot agent on data from the Chatterbot-Corpus project is relatively simple. To do that, you need to instantiate a ChatterBotCorpusTrainer object and call the train() method. The ChatterBotCorpusTrainer takes in the name of your ChatBot object as an argument. The train() method takes in the name of the dataset you want to use for training as an argument.

Detailed information about ChatterBot-Corpus Datasets is available on the project’s Github repository.

corpus_trainer = ChatterBotCorpusTrainer(BankBot)
corpus_trainer.train("chatterbot.corpus.English")

Training on custom list data

You can also train ChatterBot on custom conversations. This can be done by using the module’s ListTrainer class.

In this case, you will need to pass in a list of statements where the order of each statement is based on its placement in a given conversation. Each statement in the list is a possible response to its predecessor in the list.

The training can be undertaken by instantiating a ListTrainer object and calling the train() method. It is important to note that the train() method must be individually called for each list to be used.

greet_conversation = [
    "Hello",
    "Hi there!",
    "How are you doing?",
    "I'm doing great.",
    "That is good to hear",
    "Thank you.",
    "You're welcome."
]
open_timings_conversation = [
    "What time does the Bank open?",
    "The Bank opens at 9AM",
]
close_timings_conversation = [
    "What time does the Bank close?",
    "The Bank closes at 5PM",
]
#Initializing Trainer Object
trainer = ListTrainer(BankBot)

#Training BankBot
trainer.train(greet_conversation)
trainer.train(open_timings_conversation)
trainer.train(close_timings_conversation)

Building a front end

Once the chatbot has been trained, it can be used by calling Chatterbot’s get response() method. The method takes a user string as an input and returns a response string.

while (True):
    user_input = input()
    if (user_input == 'quit'):
        break
    response = BankBot.get_response(user_input)
    print (response)

Conclusion

This blog was hands-on to building a simple AI-based chatbot in Python. The functionality of this bot can easily be increased by adding more training examples. You could, for example, add more lists of custom responses related to your application.

As we saw, building an AI-based chatbot is easy compared to building and maintaining a Rule-based Chatbot. Despite this ease, chatbots such as this are very prone to mistakes and usually give robotic responses because of a lack of good training data.

A better way of building robust AI-based Chatbots is to use Conversational AI Tools offered by companies like Google and Amazon. These tools are based on complex machine learning models with AI that has been trained on millions of datasets. This makes them extremely intelligent and, in most cases, are almost indistinguishable from human operators.

In the next blog to learn data science, we’ll be looking at how to create a Dialog Flow Chatbot using Google’s Conversational AI Platform.

Want to upgrade your Python abilities? Check out Data Science Dojo’s Introduction to Python for Data Science.

Data Science Dojo
| April 29, 2019

High dimensional data is a necessary skill for every data scientist to have. Break the curse of dimensionality with Python.

What’s common in most of us is that we are used to seeing and interpreting things in two or three dimensions to the extent that the thought of thinking visually about the higher dimensions seems intimidating. However, you can get a grasp of the core intuition and ideas behind the enormous world of dimensions.

Let’s focus on the essence of dimensionality reduction. Many data science tasks often demand that we work with higher dimensions in the data. In terms of machine learning models, we often tend to add several features to catch salient features even though they won’t provide us with any significant amount of new information. Using these redundant features, the performance of the model will deteriorate after a while. This phenomenon is often referred to as “the curse of dimensionality”.

The curse of high dimensionality

When we keep adding features without increasing the data used to train the model, the dimensions of the feature space become sparse since the average distance between the points increases in high dimensional space. Due to this sparsity, it becomes much easier to find a convenient and perfect, but not so optimum, solution for the machine learning model. Consequently, the model doesn’t generalize well, making the predictions unreliable. You may also know it as “overfitting”. It is necessary to reduce the number of features considerably to boost the model’s performance and to arrive at an optimal solution for the model.

What if I tell you that fortunately for us, in most real-life problems, it is often possible to reduce the dimensions in our data, without losing too much of the information the data is trying to communicate? Sounds perfect, right?

Now let’s suppose that we want to get an idea about how some high-dimensional data is arranged. The question is, would there be a way to know the underlying structure of the data? A simple approach would be to find a transformation. This means each of the high-dimensional objects is going to be represented by a point on a plot or space, where similar objects are going to be represented by nearby points and dissimilar objects are going to be represented by distant points.

High Dimensional Space to Low Dimensional Space
Figure 1: Transformation from High Dimensional Space to Low Dimensional Space



High Dimensional Space to Low Dimensional Space 2
Figure 2: Transformation from High Dimensional Space to Low Dimensional Space

Figure 1 illustrates a bunch of high-dimensional data points we are trying to embed in a two-dimensional space. The goal is to find a transformation such that the distances in the low dimensional map reflect the similarities (or dissimilarities) in the original high dimensional data. Can this be done? Let’s find out.

As we can see from Figure 2, after a transformation is applied, this criterion isn’t fulfilled because the distances between the points in the low dimensional map are non-identical to the points in the high dimensional map. The goal is to ensure that these distances are preserved. Keep this idea in mind since we are going to come back on this later!

Now we will break down the broad idea of dimensionality reduction into two branches – Matrix Factorization and Neighbor Graphs. Both cover a broad range of techniques. Let’s look at the core of Matrix Factorization.

matrix factorization
Figure 3: Matrix Factorization

Matrix factorization

The goal of matrix factorization is to express a matrix as approximately a product of two smaller matrices. Matrix A represents the data where each row is a sample and each column, a feature. We want to factor this into a low dimensional interpretation UU, multiplied by some exemplars VV, which are used to reconstruct the original data. A single sample of your data can be represented as one row of your interpretation UiUi, which acts upon the entire matrix of the exemplars VV. Therefore, each individual row of matrix A can be represented as a linear combination of these exemplars and the coefficients of that linear combination are your low dimensional representation. This is matrix factorization in a nutshell.

You might have noticed the approximation sign in Figure 3 and while reading the above explanation you might have wondered why are we using the approximation sign here? If a bigger matrix can be broken down into two smaller matrices, then shouldn’t they both be equal? Let’s figure that out!

In reality, we cannot decompose matrix AA such that it’s exactly equal to  U⋅VU⋅V. But what we would like to do is to break down a matrix such that U⋅VU⋅V is as close as possible to AA when reconstructed using the representation UU and exemplars VV. When we talk about approximation, we are trying to introduce the notion of optimization. This means that we’re going to try and minimize some form of error, which is between our original data AA and the reconstructed data A′A′ subject to some constraints. Variations of these losses and constraints give us different matrix factorization techniques. One such variation brings us to the idea of Principle Component Analysis.

Neighbor graphs: The theme revolves around building a graph using the data and embedding that graph in a low-dimensional space. There are two queries to be answered at this point. How do we build a graph and then how do we embed that graph? Assume there is some data that has some non-linear low dimensional structure to it. A linear approach like PCA will not be able to find it. However, if we somehow draw a graph of the data where each point close to or a k-nearest neighbor of that point is linked with an edge, then there is a fair chance that the graph might be able to uncover the structure that we wanted to find. This technique introduces us to the idea of t-distributed stochastic neighbor embedding.

Now let’s begin the journey to find how these transformations work using the algorithms introduced.

Principal components analysis



Scatter plot
Figure 4: Scatter Plot



Let’s follow the logic behind PCA. Figure 4 shows a scatter plot of points in 2D. You can clearly see two different colors. Let’s think about the distribution of the red points. These points must have some mean value ¯xx¯ and a set of characteristic vectors V1V1 and V2V2. What if I tell you that the red points can be represented using only their V1V1 coordinates plus the mean. Basically, we can think of these red points on a line and all you will be given is their position on the line. This is essentially giving out the coordinates for the xx axis while ignoring the yy coordinates since we don’t care by what amount are the points off the line. So we have just reduced the dimensions from 2 to 1.

Going by this example, it doesn’t look like a big deal. But in higher dimensions, this could be a great achievement. Imagine you’ve got something in 20,000-dimensional space. If somehow you are able to find a representation of approximately around 200 dimensions, then that would be a huge reduction.

Now let me explain PCA from a different perspective. Suppose, you wish to differentiate between different food items based on their ingredients. According to you, which variable will be a good choice to differentiate food items? If you choose an ingredient that varies a lot from one food item to another and is not common among different foods, then you will be able to draw a difference quite easily. The task will be much more complex if the chosen variable is consistent across all the food items. Coming back to reality, we don’t usually find such variables which segregate the data perfectly into various classes. Instead, we have the ability to create an entirely new variable through a linear combination of original variables such that the following equation holds:

Y=2×1−3×2+5x3Y=2×1−3×2+5×3

Recall the concept behind linear combination from matrix factorization. This is what PCA essentially does. It finds the best linear combinations of the original variables so that the variance or spread along the new variable is maximum. This new variable YY is known as the principle component. PCA1PCA1 captures the maximum amount of variance within our data, and PCA2PCA2 accounts for the largest remaining variance in our data,  and so on. We talked about minimizing the reconstruction error in matrix factorization. Classical PCA employs mean squared error as a loss between the original and reconstructed data.

MNIST Visualization using PCA
Figure 5: MNIST Visualization using PCA



Let’s generate a three-dimensional plot for PCA/reduced data using the MNIST-dataset with the help of Hypertools. This is a Python toolbox for gaining geometric insights into high-dimensional data. The dataset consists of 70,000 digits consisting of 10 classes in total. The scatter plot in Figure 5 shows a different color for each digit class. From the plot, we can see that the low dimensional space holds some significant information since a bunch of clusters are visible. One thing to note here is that the colors are assigned to the digits based on the input labels which were provided with the data.

But what if this information wasn’t available? What if we convert the plot into a grayscale image? You’d not be able to make much out of it, right? Maybe on the bottom right, you would see a little bit of high-density structure. But it would basically just be one blob of data. So, the question is can we do better? Is PCA minimizing the right objective function/loss? And if you think about PCA, then basically what it’s doing, it’s mainly concerned with preserving large pairwise distances in the map. It’s trying to maximize variance which is sort of the same as trying to minimize a squared error between distances in the original data and distances on the map. When you are looking at the squared error, you’re mainly concerned with preserving distances that are very large.

Is this what an informative visualization of the low-dimensional space should look like? Definitely not. If you think about the data in terms of a nonlinear manifold (Figure 6), then you would see that in this case, the Euclidean distance between two points on this manifold would not reflect their true similarity quite accurately. The distance between these two points suggests that these two are similar, whereas if you consider the entire structure of the data manifold, then they are very far apart. The key idea is that the PCA doesn’t work so well for visualization because it preserves large pairwise distances which are not reliable. This brings us to our next key concept.

Non-Linear Manifold graph
Figure 6: Non-Linear Manifold

t-stochastic Neighboring Embedding (t-SNE)

In a high-dimensional space, the intent is to measure only the local similarities between points, which basically means measuring similarities between the nearby points.

High to Low Dimensional Space
Figure 7: Map from High to Low Dimensional Space



Looking at Figure 7, let’s focus on the yellow data point in the high dimensional space. We are going to center a Gaussian over this point xijxij to measure the density of all the other points under this Gaussian. This gives us a set of probabilities pijpij, which basically measures the similarity between pairs of points ij. This probability distribution describes a pair of points, where the probability of picking any given pair of points is proportional to the similarity. If two points are close together in the original high dimensional, the value for pijpij is going to be large. If two points are dissimilar in space then pijpij is basically going to be infinitesimal.

Let’s now devise a way to use these local similarities to achieve our initial goal of reducing dimensions. We will look at the two/three-dimensional space. This will be our final map after transformation. The yellow point can be represented using yiyi. The same approach will be implemented here as well. We are going to center another kernel over this point yiyi to measure the density of all the other points under this distribution. This gives us a probability qijqij, which measures the similarity of two points in the low dimensional space. The goal is that these probabilities qijqij should reflect the similarities pijpij as effectively as possible. To retain and uncover the underlying structure in the data, all of qijqij should be identical to all of pijpij so that the structure of the transformed data is quite similar to the structure of the data in the original high dimensional space.

To check the similarity between these distributions we use a different measure known as KL divergence. This ensures that if two points are close in the original space, then the algorithm will ensure to place them in the vicinity in the low dimensional space. Conversely, if the two points are far apart in the original space, the algorithm is relatively free to place these points around. We want to lay out these points in the low dimensional space to minimize the distance between these two probability distributions to ensure that the transformed space is a model of the original space. Again, a mathematical algorithm known as gradient descent is applied to KL divergence, which is just moving the points around in space iteratively to find the optimum setting in the low dimensional space so that this KL divergence becomes as small as possible.

The key takeaway here is that the high dimensional space distance is based on a Gaussian distribution, however, we are using a Student-t distribution in the embedded space. This is also known as heavy-tailed Student-t distribution. This is where the t in t-SNE comes from.

This whole explanation boils down to one question: Why this distribution? So let’s suppose we want to project the data down to two dimensions from a 10-dimensional hyper-cube. If we think realistically then we can never preserve all the pairwise distances accurately. We need to compromise and find a middle ground somewhere. t-SNE tried to map similar points close to each other and dissimilar ones far apart.

Figure 8 illustrates this concept, where we have three points in the two-dimensional space. The yellow lines are the small distances that represent the local structure. The distance between the corner of the triangle is a global structure so it is denoted as a large pairwise distance. We want to transform this data into one-dimensional while preserving local structure. Once the transformation is done, you can see that the distance between the two points that are far apart has grown. Using the heavy tail distribution, we are allowing this phenomenon to happen. If we have two points that have a pairwise distance of let’s say 20, and using a Gaussian gives a density of 2, then to get the same density under the student t-distribution, because of the heavy tails, these points have to be 30 or 40 apart. So for dissimilar points, the heavy-tailed qijqij basically allows dissimilar points to be modeled far apart in the map than they were in the original space.



points in two-dimensional space
Figure 8: Three points in two-dimensional space



Let’s try to run the algorithm using the same dataset. I have used Dash to build a t-SNE visualization. Dash is a productive Python framework for building data visualization apps. This can be rendered in the web browser. A great thing is that you can hover over a data point to check from which class it belongs to. Isn’t that amazing? All you need to do is to input your data in CSV format and it does the magic for you.

So, what you see here is t-SNE running gradient descent, doing the learning while calculating KL divergence. There is much more structure than there is in the PCA plot. You can see that the 10 different digits are well separated in the low-dimensional map. You can vary the parameters and monitor how the learning varies. You may want to read this great article distilling how to interpret the results of t-SNE. Remember, the labels of the digits were not used to generate this embedding. The labels are only used for the purpose of coloring the plot. t-SNE is a completely unsupervised algorithm. This is a huge improvement over PCA because if we didn’t even have the labels and colors then we would still be able to separate out the clusters.

MNIST visualization using t-SNE
Figure 9: MNIST visualization using t-SNE

Autoencoders

Architecture_of_an_auto-encoder-1
Figure 10: Architecture of an auto-encoder

The word ‘auto-encoder‘ has been floating around for a while now. Auto-encoder may sound like a cryptic name at first but it’s not. It is basically a computational model whose aim is to learn a representation or encoding for some sort of data. Fortunately for us, this encoding can be used for the task of dimensionality reduction.

To explain the working of auto-encoders in the simplest terms, let’s look back at what PCA was trying to do. All PCA does is that it finds a new coordinate system for your data such that it aligns with the orientation of maximum variability in the data. This is a linear transformation since we are simply rotating the axis to end up in a new coordinate system. One variant of an auto-encoder can be used to generalize this linear dimension reduction.

How does it do that?

As you can see in Figure 10, there are a bunch of hidden units where the input data is passing. The input and output units of an auto-encoder are identical since the idea is to learn an un-supervised compression of our data using the input. The latent space contains a compressed representation of the image, which is the only information the decoder is allowed to use to try to reconstruct the input. If these units and the output layers are linear then the auto-encoder will learn a linear function of the data and try to minimize the squared reconstruction error.

That’s what PCA was doing, right? In terms of principle components, the first N hidden units will represent the same space as the first N components found by PCA, which accounts for the maximum variance. In terms of learning, auto-encoders go beyond this. They can be used to learn complex non-linear manifolds, as well as uncover the underlying structure of data.

In the PCA projection (Figure 11),  you can see that’s how the clusters are merged for the digits 5, 3, and 8 and that’s sole because they are all made up of similar pixels. This visualization is as a result of capturing a 19.8% variance in the original data set only.

Coming towards t-SNE, now we can hope that it will give us a much more fascinating projection of the latent space. The projection shows denser clusters. This shows that in the latent space, the same digits are close to one another. We can see that the digits 5, 3, and 8 are now much easier to separate and appear in small clusters as the axis rotates.

These embeddings on the raw mnist input images have enabled us to visualize what the encoder has managed to encode in its compressed layer representation. Brilliant!

Figure 11: PCA visualization of the Latent Space



Explore

Phew, so many techniques! Well, there are a bunch of other techniques that we have not discussed here. It will be very difficult to identify an algorithm that always works better than all the rest. The superiority of one algorithm over another depends on the context and the problem we are trying to solve. What is common in all these algorithms is that the algorithms try to preserve some properties and sacrifice some other, in order to achieve some specific goal. You should dive deep and explore these algorithms for yourself! There is always a possibility that you can discover a new perspective that works well for you.

In the famous words of Mick Jagger, “You can’t always get what you want, but if you try sometimes, you just might find you get what you need.”

Learn more about high dimensional data

Stephanie Donahole
| May 29, 2019

Data Science is a hot topic in the job market these days. What are some of the best places for Data Scientists and Engineers to work in?

To be honest, there has never been a better time than today to learn data science. The job landscape is quite promising, opportunities span multiple industries, and the nature of the job often allows for remote work flexibility and even self-employment. The following post emphasizes the top cities across the globe with the highest pay packages for data scientists.

Industries across the globe keep diversifying on a constant basis. With technology reaching new heights and a majority of the population having unlimited access to an internet connection, there is no denying the fact that big data and data analytics have started gaining momentum over the years. Demand for data analytics professionals currently outweighs the supply, meaning that companies are willing to pay a premium to fill their open job positions. Further below, I would like to mention certain skills required for a job in data analytics.

Python

Being one of the most used programming languages, Python has a solid understanding of how it can be used for data analytics. Even if it’s not a required skill, knowledge and understanding of Python will give you an upper hand when showing future employers the value that you can bring to their companies. Just make sure you learn how to manipulate and analyze data, understand the concept of web scraping and data collection, and start building web applications.

SQL (Structured Query Language)

Like Python, SQL is a relatively easy language to start learning. Even if you are just getting started, a little SQL experience goes a long way. This will give you the confidence to navigate large databases, and to obtain and work with the data you need for your projects. You can always seek out opportunities to continue learning once you get your first job.

Data visualization

Regardless of the career path, you are looking into, it is crucial to visualize and communicate insights related to your company’s services, and is a valuable skill set that will capture the attention of employers. Data scientists are a bit like data translators for other people who exactly know what conclusions to draw from their datasets.

Best opportunities for a data scientist

Have a look at cities across the globe that offer the best opportunities for the position of a data scientist. The order of the cities does not represent any type of rank.

salary graph
Average Salary of a Data Scientist in US Dollars
  1. San Jose, California – Have you ever dreamed about working in Silicon Valley? Who hasn’t? It’s the dream destination of any tech enthusiast and an emerging hot spot for data scientists all across the globe. Being an international headquarters and main offices of the majority of the American tech corporations, it offers a plethora of job opportunities and high pay. It may interest you to know that the average salary of a chief data scientist is estimated to be $132,355 per year.
  2. Bengaluru, India – Second city on the list is Bengaluru, India. The analytics market is touted to be the best in the country, with the state government, analytics startups, and tech giants contributing substantially to the overall development of the sector. The average salary is estimated to be ₹ 12 lakh per annum ($17,240.40).
  3. Berlin, Germany – If we look at other European countries, Germany is home to some of the finest automakers and manufacturers. Although, the country isn’t much explored to newer and better opportunities in the field of data science it seems to be expanding its portfolio day in and day out. If you are a data scientist you may earn around €11,000 but if you are a chief data scientist then you will not be earning less than €114,155.
  4. Geneva, Switzerland – If you are seeking around for one of the highest paying cities in this beautiful paradise; it is Geneva. Call yourself fortunate, if you happen to land a position as a data scientist. The mean salary of a researcher starts at 180,000 Swiss Fr, and a chief data scientist can earn as much as 200,000 Swiss Fr with an average bonus ranging between 9,650-18,000 Swiss Fr.
  5. London, United Kingdom – One of the top destinations in Europe that offers high-paying and reputable jobs in London. UK government seems to rely on technologies day in and day out due to which the number of opportunities in the field has gone up substantially with the average salary of a Data Scientist being £61,543.

I also included the average data scientist salaries from the 20 largest cities around the world in 2019:

  1. Tokyo, Japan: $56,783
  2. New York City, USA: $115,815
  3. Mexico City, Mexico: $32,487
  4. Sao Paolo, Brazil: $45,891
  5. Los Angeles, USA: $120,179
  6. Shanghai, China: $66,014
  7. Mumbai, India: $29,695
  8. Seoul, South Korea: $45,993
  9. Osaka, Japan $54,417
  10. London, UK: $56,820
  11. Lagos, Nigeria: $48,771
  12. Calcutta, India: $7,423
  13. Buenos Aires, Argentina: $40,512
  14. Paris, France: $37,861
  15. Rio de Janeiro, Brazil: $54,191
  16. Karachi, Pakistan: $6,453
  17. Delhi, India: $20,621
  18. Manila, Philippines: $47,414
  19. Istanbul, Turkey: $30,210
  20. Beijing, China: $72,801

Related Topics

Web Development
Top
Statistics
Software Testing
Programming Language
Podcasts
Natural Language
Machine Learning
Hypothesis Testing
High-Tech
Events
Discussions
Demos
Data Visualization
Data Security
Data Science
Data Mining
Data Engineering
Data Analytics
Conferences

Up for a Weekly Dose of Data Science?

Subscribe to our weekly newsletter & stay up-to-date with current data science news, blogs, and resources.
