# Classification using decision trees – A comprehensive tutorial

August 18, 2022

Complete the tutorial to revisit and master the fundamentals of decision trees and classification models, one of the simplest and easiest models to explain.

### Introduction

Data Scientists use machine learning techniques to make predictions under a variety of scenarios. Machine learning can be used to predict whether a borrower will default on his mortgage or not, or what might be the median house value in a given zip code area. Depending upon whether the prediction is being made for a quantitative variable or a qualitative variable, a predictive model can be categorized as a regression model (e.g. predicting median house values) or a classification (e.g. predicting loan defaults) model.

Decision trees happen to be one of the simplest and easiest classification models to explain and, as many argue, closely resemble human decision-making.

This tutorial has been developed to help you revisit and master the fundamentals of decision tree classification models which are expanded on in Data Science Dojo’sÂ data science bootcampÂ andÂ online data science certificateÂ program. Our key focus will be to discuss the:

1. Fundamental concepts on data-partitioning, recursive binary splitting, nodes, etc.
2. Data exploration and data preparation for building classification models
3. Performance metrics for decision tree models – Gini Index, Entropy, and Classification Error.

The content builds your classification model knowledge and skills in an intuitive and gradual manner.

### The scenario

You are a Data Scientist working at the Centers for Disease Control (CDC) Division for Heart Disease and Stroke Prevention. Your division has recently completed a research study to collect health examination data among 303 patients who presented with chest pain and might have been suffering from heart disease.

The Chief Data Scientist of your division has asked you to analyze this data and build a predictive model that can accurately predict patients’ heart disease status, identifying the most important predictors of heart failure. Once your predictive model is ready, you will make a presentation to the doctors working at the health facilities where the research was conducted.

The data set has 14 attributes, including patients’ age, gender, blood pressure, cholesterol level, and heart disease status, indicating whether the diagnosed patient was found to have heart disease or not. You have already learned that to predict quantitative attributes such as “blood pressure” or “cholesterol level”, regression models are used, but to predict a qualitative attribute such as the “status of heart disease,”Â  classification models are used.

Classification models can be built using different techniques such as Logistic Regression, Discriminant Analysis, K-Nearest Neighbors (KNN), Decision Trees, etc. Decision Trees are very easy to explain and can easily handle qualitative predictors without the need to create dummy variables.

Although decision trees generally do not have the same level of predictive accuracy as the K-Nearest Neighbor or Discriminant Analysis techniques, They serve as building blocks for other sophisticated classification techniques such as “Random Forest” etc. which makes mastering Decision Trees, necessary!

We will now build decision trees to predict the status of heart disease i.e. to predict whether the patient has heart disease or not, and we will learn and explore the following topics along the way:

• Data preparation for decision tree models
• Classification trees using “rpart” package
• Pruning the decision trees
• Evaluating decision tree models

``## You will need following libraries for this exercise ``
``````library(dplyr)
library(tidyverse)
library(ggplot2)
library(rpart)
library(rpart.plot)
library(rattle)
library(RColorBrewer)

## Following code will help you suppress the messages and warnings during package loading
options(warn = -1) ``````

### The data

You will be working with theÂ Heart Disease Data SetÂ which is available at UC Irvine’sÂ Machine Learning Repository.Â You are encouraged to visit the repository and go through the data description. As you will find, the data folder has multiple data files available. You will use theÂ processed.cleveland.data.

Let’s read the datafile into a data frame “cardio”

``````## Reading the data into "cardio" data frame
cardio <- read.csv("processed.cleveland.data", header = FALSE, na.strings = '?')
``````
``````## Let's look at the first few rows in the cardio data frame
``````
V1 V2 V3 V4 V5 V6 V7 V8 V9 V10 V11 V12 V13 V14
63 1 1 145 233 1 2 150 0 2.3 3 0 6 0
67 1 4 160 286 0 2 108 1 1.5 2 3 3 2
67 1 4 120 229 0 2 129 1 2.6 2 2 7 1
37 1 3 130 250 0 0 187 0 3.5 3 0 3 0
41 0 2 130 204 0 2 172 0 1.4 1 0 3 0
56 1 2 120 236 0 0 178 0 0.8 1 0 3 0

As you can see, this data frame doesn’t have column names. However, we can refer to the data dictionary, given below, and add the column names:

Column Position Attribute Name Description Attribute Type
#1 Age Age of Patient Quantitative
#2 Sex Gender of Patient Qualitative
#3 CP Type of Chest Pain (1: Typical Angina, 2: Atypical Angina, 3: Non-anginal Pain, 4: Asymptomatic) Qualitative
#4 Trestbps Resting Blood Pressure (in mm Hg on admission) Quantitative
#5 Chol Serum Cholestrol in mg/dl Quantitative
#6 FBS (Fasting Blood Sugar>120 mg/dl) 1=true; 0=false Qualitative
#7 Restecg Resting ECG results (0=normal; 1 and 2 = abnormal) Qualitative
#8 Thalach Maximum heart Rate Achieved Quantitative
#9 Exang Exercise Induced Angina (1=yes; 0=no) Qualitative
#10 Oldpeak ST Depression Induced by Exercise Relative to Rest Quantitative
#11 Slope The slope of peak exercise st segment (1=upsloping; 2=flat; 3=downsloping) Qualitative
#12 CA Number of major vessels (0-3) colored by flourosopy Qualitative
#13 Thal Thalassemia (3=normal; 6=fixed defect; 7=reversable defect) Qualitative
#14 NUM Angiographic disease status (0=no heart disease; more than 0=no heart disease) Qualitative

The following code chunk will add column names to your data frame:

``````## Adding column names to dataframe
names(cardio) <- c( "age", "sex", "cp", "trestbps", "chol","fbs", "restecg",
"thalach","exang", "oldpeak","slope", "ca", "thal", "status")
``````

You are going to build a decision tree model to predict values under variable #14Â status, the “angiographic disease status” whichÂ labelsÂ orÂ classifiesÂ each patient asÂ “having heart disease”Â orÂ “not having heart disease.

Intuitively, we expect some of these other 13 variables to help us predict the values underÂ status. In other words, we expect variables #1 to #13, toÂ segment the patientsÂ or createÂ partitions in the cardio data frameÂ inÂ a manner that any givenÂ partitionÂ (or segment) thus created either has patients asÂ “having heart disease”Â orÂ “not having heart disease.

### Data preparation for decision trees

It is time to get familiar with the data. Let’s begin with data types.

``````## We will use str() function
str(cardio)``````
``````'data.frame':	303 obs. of  14 variables:
\$ age      : num  63 67 67 37 41 56 62 57 63 53 ...
\$ sex      : num  1 1 1 1 0 1 0 0 1 1 ...
\$ cp       : num  1 4 4 3 2 2 4 4 4 4 ...
\$ trestbps : num  145 160 120 130 130 120 140 120 130 140 ...
\$ chol     : num  233 286 229 250 204 236 268 354 254 203 ...
\$ fbs      : num  1 0 0 0 0 0 0 0 0 1 ...
\$ restecg  : num  2 2 2 0 2 0 2 0 2 2 ...
\$ thalach  : num  150 108 129 187 172 178 160 163 147 155 ...
\$ exang    : num  0 1 1 0 0 0 0 1 0 1 ...
\$ oldpeak  : num  2.3 1.5 2.6 3.5 1.4 0.8 3.6 0.6 1.4 3.1 ...
\$ slope    : num  3 2 2 3 1 1 3 1 2 3 ...
\$ ca       : num  0 3 2 0 0 0 2 0 1 0 ...
\$ thal     : num  6 3 7 3 3 3 3 3 7 7 ...
\$ status   : int  0 2 1 0 0 0 3 0 2 1 ...
``````

As you can see, someÂ qualitativeÂ variables in our data frame are included asÂ quantitativeÂ variables

• statusÂ is declared as \$\$ which makes it a quantitative variable but we know disease status must beÂ qualitative
• You can see thatÂ sex,Â cp,Â fbs,Â restecg,Â exang, Â slope,Â ca,Â andÂ thalÂ too
must beÂ qualitative

The next code-chunk will convert and correct the datatypes:

``````## We can use lapply to convert data types across multiple columns
cardio[c("sex", "cp", "fbs","restecg", "exang",
"slope", "ca", "thal", "status")] <- lapply(cardio[c("sex", "cp", "fbs","restecg",
"exang", "slope", "ca", "thal", "status")], factor)
## You can verify the data frame
str(cardio)
``````
``````'data.frame':	303 obs. of  14 variables:
\$ age     : num  63 67 67 37 41 56 62 57 63 53 ...
\$ sex     : Factor w/ 2 levels "0","1": 2 2 2 2 1 2 1 1 2 2 ...
\$ cp      : Factor w/ 4 levels "1","2","3","4": 1 4 4 3 2 2 4 4 4 4 ...
\$ trestbps: num  145 160 120 130 130 120 140 120 130 140 ...
\$ chol    : num  233 286 229 250 204 236 268 354 254 203 ...
\$ fbs     : Factor w/ 2 levels "0","1": 2 1 1 1 1 1 1 1 1 2 ...
\$ restecg : Factor w/ 3 levels "0","1","2": 3 3 3 1 3 1 3 1 3 3 ...
\$ thalach : num  150 108 129 187 172 178 160 163 147 155 ...
\$ exang   : Factor w/ 2 levels "0","1": 1 2 2 1 1 1 1 2 1 2 ...
\$ oldpeak : num  2.3 1.5 2.6 3.5 1.4 0.8 3.6 0.6 1.4 3.1 ...
\$ slope   : Factor w/ 3 levels "1","2","3": 3 2 2 3 1 1 3 1 2 3 ...
\$ ca      : Factor w/ 4 levels "0","1","2","3": 1 4 3 1 1 1 3 1 2 1 ...
\$ thal    : Factor w/ 3 levels "3","6","7": 2 1 3 1 1 1 1 1 3 3 ...
\$ status  : Factor w/ 5 levels "0","1","2","3",..: 1 3 2 1 1 1 4 1 3 2 ...
``````

Also, note that statusÂ has 5 different values viz. 0, 1, 2, 3, 4. WhileÂ status = 0, indicatesÂ no heart disease, all other values underÂ statusÂ indicateÂ aÂ heart disease. In this exercise, you are building a decision tree model to classify each patient asÂ “normal”(not having heart disease) orÂ “abnormal”Â (having heart disease)”.

Therefore, you can mergeÂ status = 1, 2, 3, and 4 into a single-levelÂ status = “1”. This way you will convertÂ statusÂ into a Â BinaryÂ orÂ DichotomousÂ variableÂ having only two valuesÂ status = “0” (normal)Â andÂ status = “1” (abnormal)

Let’s do that!

``````##  We will use the 'forcats' package included in the s'tidyverse' package
##  The function to be used will be fct_collpase
cardio\$status <- fct_collapse(cardio\$status, "1" = c("1","2", "3", "4"))

## Let's also change the labels under the "status" from (0,1) to (normal, abnormal)
levels(cardio\$status) <- c("normal", "abnormal")

## levels under sex can also be changed to (female, male)
## We can change level names in other categorical variables as well but we are not doing that
levels(cardio\$sex) <- c("female", "male")
``````

So, you have corrected the data types. What’s next?

How about getting a summary of all the variables in the data?

``````## Overall summary of all the columns
summary(cardio)
``````
``````      age            sex      cp         trestbps          chol       fbs
Min.   :29.00   female: 97   1: 23   Min.   : 94.0   Min.   :126.0   0:258
1st Qu.:48.00   male  :206   2: 50   1st Qu.:120.0   1st Qu.:211.0   1: 45
Median :56.00                3: 86   Median :130.0   Median :241.0
Mean   :54.44                4:144   Mean   :131.7   Mean   :246.7
3rd Qu.:61.00                        3rd Qu.:140.0   3rd Qu.:275.0
Max.   :77.00                        Max.   :200.0   Max.   :564.0

restecg    thalach      exang      oldpeak     slope      ca        thal
0:151   Min.   : 71.0   0:204   Min.   :0.00   1:142   0   :176   3   :166
1:  4   1st Qu.:133.5   1: 99   1st Qu.:0.00   2:140   1   : 65   6   : 18
2:148   Median :153.0           Median :0.80   3: 21   2   : 38   7   :117
Mean   :149.6           Mean   :1.04           3   : 20   NA's:  2
3rd Qu.:166.0           3rd Qu.:1.60           NA's:  4
Max.   :202.0           Max.   :6.20

status
normal  :164
abnormal:139

``````

Did you notice the missing values (NAs) under the caÂ andÂ thalÂ columns? With the following code, you can count the missing values across all the columns in your data frame.

``````# Counting the missing values in the datframe
sum(is.na(cardio))
``````
``6``

Only 6 missing values across 303 rows which is approximatelyÂ 2%. That seems to be a very low proportion of missing values. What do you want to do with these missing values, before you start building your decision tree model?

• Option 1: discard the missing values before training.
• Option 2: rely on theÂ machine learning algorithm to deal with missing values during the model training.
• Option 3: impute missing values before training.

For most learning methods, Option 3Â the imputation approach is necessary. The simplest approach is to impute the missing values by theÂ meanÂ orÂ medianÂ of the non-missing values for the given feature.

The choice of Option 2 depends on the learning algorithm. Learning algorithms such asÂ CARTÂ andÂ rpart simply ignore missing values when determining the quality of a split. To determine, whether a case with a missing value for the best split is to be sent left or right, the algorithm uses surrogate splits. You may want to read more on this here.

However, if the relative amount of missing data is small, you can go for Option 1 and discard the missing values as long as it doesn’t lead to or further alleviate theÂ class imbalance which is brieflyÂ discussed in the following section.

As for your data set, you are safe to delete missing value cases. The following code-chunk does that for you.

``````## Removing missing values
cardio <- na.omit(cardio)
``````

### Data exploration

StatusÂ is the variable that you want to predict with your model. As we have discussed earlier, other variables in theÂ cardioÂ dataset should help you predictÂ status.

For example, amongst patients with heart disease, you might expect the average value of Cholesterol levels (chol), to be higher than amongst those who are normal. Likewise, amongst patients with high blood sugar (fbs = 1), the proportion of patients with heart disease would be expected to be higher than what it is amongst normal patients. You can do some data visualization and exploration.

You may want to start with a distribution of status. The following code-chunk will provide you with:

``````## plotting a histrogram for status
cardio %>%
ggplot(aes(x = status)) +
geom_histogram(stat = 'count', fill = "steelblue") +
theme_bw()
``````

From this histogram, you can observe that there is almost an equal split between patients having status asÂ normal andÂ abnormal.

This may not always be the case. There might be datasets in which one of the classes in the predicted variable has a very low proportion. Such datasets are said to have a class imbalance problemÂ where one of the classes in theÂ predicted variable is rare within the dataset.

AÂ Credit Card Fraud Detection ModelÂ or aÂ Mortgage Loan Default Model are some examples of classification models that are built with a dataset having a class imbalance problem. What other scenariosÂ come to your mind?

You are encouraged to read this article:Â ROSE: A Package for Binary Imbalanced Learning

You should now explore the distribution ofÂ quantitative variables. You can make density plots with frequency counts on the Y-axis and split the plot by the two levels in theÂ statusÂ variable.

The following code will produce the plots arranged in a grid of 2 rows

``````## frequency plots for quantitative variables, split by status
cardio %>%
gather(-sex, -cp, -fbs, -restecg, -exang, -slope, -ca, -thal, -status, key = "var", value = "value") %>%
ggplot(aes(x = value, y = ..count.. , colour = status)) +
scale_color_manual(values=c("#008000", "#FF0000"))+
geom_density() +
facet_wrap(~var, scales = "free",  nrow = 2) +
theme_bw()
``````

What are your observations from theÂ quantitativeÂ plots? Some of your observations might be:

• In all the plots, as we move along theÂ X-axis, theÂ abnormalÂ curve, mostly but not always, lies below theÂ normal curve. You should expect this, as the total number of patients with abnormalÂ is
smaller. However, for some values on theÂ X-axis (which could be smaller values of XÂ or larger, depending upon the predictor), theÂ abnormalÂ curve lies above.
• For example, look at theÂ ageÂ plot. TillÂ x = 55 years, the majority of patients are included in theÂ normalÂ curve. OnceÂ x > 55Â years, the majority goes to patients
with
abnormalÂ and remains so untilÂ x = 68Â years. Intuitively,Â ageÂ could be a good predictor ofÂ statusÂ and you may want to partition the data atÂ x = 55Â years
and then again atÂ x = 68Â years. When you build your decision tree model, you may expectÂ internal nodesÂ withÂ x > 55Â years andÂ x > 68Â years.
• Next, observe the plot forÂ chol. Except for a narrow range (x = 275 mg/dl to x = 300 mg/dl), theÂ normalÂ curve always lies above theÂ abnormalÂ curve. You may want to
form a hypothesis that Cholesterol is not a good predictor ofÂ status. In other words, you may not expectÂ cholÂ to be amongst the earliestÂ internal nodesÂ in your decision
tree model.

Likewise, you can make hypotheses for other quantitative variables as well. Of course, your decision tree model will help you validate your hypothesis.

Now you may want to turn your attention toÂ qualitativeÂ variables.

``````## frequency plots for qualitative variables, split by status
cardio %>%
gather(-age, -trestbps, -chol, -thalach, -oldpeak, -status, key = "var", value = "value") %>%
ggplot(aes(x = value, color = status)) +
scale_color_manual(values=c("#008000", "#FF0000"))+
geom_histogram(stat = 'count', fill = "white") +
facet_wrap(~var, nrow = 3) +
facet_wrap(~var, scales = "free",  nrow = 3) +
theme_bw()
``````

What are your observations from theÂ qualitativeÂ plots? How do you want to partition data along theÂ qualitativeÂ variables?

• Observe theÂ cp or the chest pain plot. The presence of asymptotic chest pain indicated byÂ cp = 4, could provide a partition in the data and could be among the earliest nodes in your decision tree.
• Likewise, observe theÂ sexÂ plot. Clearly, the proportion ofÂ abnormal is much lower (approximately 25%) amongÂ femalesÂ compared to the proportion amongÂ malesÂ (approximately
50%). Intuitively,Â sexÂ might also be a good predictor and you may want to partition the patients’ data alongÂ sex. When you build your decision tree model, you may expect internal nodesÂ withÂ sex.

At this point, you may want to go back to both plots and list down the partition (variables and, more importantly,Â variable values) that you expect to find in your decision tree model.

Of course, all our hypotheses will be validated once we build our decision tree model.

### Partitioning data: Training and test sets

Before you start building your decision tree, split theÂ cardio data into a training set and test set:

cardio.train: 70% of the dataset

cardio.test: 30% of the dataset

The following code-chunk will do that:

``````## Now you can randomly split your data in to 70% training set and 30% test set
## You should set seed to ensure that you get the same training vs/ test split every time you run the code
set.seed(1)

## randomly extract row numbers in cardio dataset which will be included in the training set
train.index <- sample(1:nrow(cardio), round(0.70*nrow(cardio),0))

## subset cardio data set to include only the rows in train.index to get cardio.train
cardio.train <- cardio[train.index, ]

## subset cardio data set to include only the rows NOT in train.index to get cardio.test
## Did you note the negative sign?
cardio.test <- cardio[-train.index,  ]
``````

### Classification trees using rpart

#### “rpart” Package

You will now useÂ rpartÂ package to build your decision tree model. The decision tree that you will build, can be plotted using packagesÂ rpart.plotÂ orÂ rattle which providesÂ better-looking plots.

You will use functionÂ rpart() to build your decision tree model. The function has the following key arguments:

formula:Â rpart(, …)

The formula where you declare what predictors you are using in your decision tree. You can specify status ~.Â to indicate that you want to use all the predictors in your decision tree.

method:Â rpart(method = < >, …)

The same function can be used to build a decision tree as well as a regression tree. You can use “class”Â to specify that you are using rpart() function for building a classification tree. If you were building a regression tree,Â you would specifyÂ “anova”Â instead.

cpÂ rpart(cp = <>,…)

The main role of the Complexity Parameter (cp) is to control the size of the decision tree. Any split that does not reduce the tree’s overall complexity by a factor ofÂ cpÂ is not attempted. The default valueÂ is Â 0.01. A value ofÂ cp = 1 will result in a tree with no splits. Setting cp to negative values ensures a fully grown tree.

minsplitÂ Â rpart( minsplit = <>, …)

The minimum number of observations must exist in a node in order for a split to be attempted. The default value is 20.

minbucketÂ Â rpart( minbucket = <>, …)

The minimum number of observations in any terminal node. If only one minbucket or minsplit is specified, the code either sets minsplit to minbucket*3 or minbucket to minsplit/3, which is the default.

You are encouraged to read the package documentationÂ rpart documentation

You can build a decision tree using all the predictors and with aÂ cp = 0.05. The following code chunk will build your decision tree model:

``````## using all the predictors and setting cp = 0.05
cardio.train.fit <- rpart(status ~ . , data = cardio.train, method = "class", cp = 0.05)
``````

It is time to plot your decision tree. You can use the function rpart.plot() for plotting your tree. However, the function fancyRpartPlot() in theÂ rattleÂ package is more ‘fancy’

``````## Using fancyRpartPlot() from "rattle" package
fancyRpartPlot(cardio.train.fit, palettes = c("Greens", "Reds"), sub = "")``````

### Interpreting decision tree plot

What are your observations from your decision tree plot?

Each square box is aÂ nodeÂ of one or the other type (discussed below):

Root NodeÂ cp =Â 1, 2, 3: The root node represents the entire population or 100% of the sample.

Decision Nodes thal = 3, and ca = 0: These are the two internal nodes that get split up either in further internal nodes or in terminal nodes. There are 3 decision nodes here.

Terminal Nodes (Leaf): The nodes that do not split further are called terminal nodes or leaves. Your decision tree has 4 terminal nodes.

The decision tree plot gives the following information:

Predictors Used in Model: Only theÂ thal,Â cp, andÂ caÂ variables are included in this decision tree.

Predicted Probabilities: Predicted probability of a patient beingÂ normalÂ orÂ abnormal. Note that the two probabilities add to 100%, at each node.

Node Purities: Each node has two proportions written left and right. The leftmost leaf has 0.82 and 0.18. The number on the left, 0.82 tells you what proportion of the node actually belongs to the predicted class. You can see that this leaf has 82% purity.

Sample Proportion: Each node has a proportion of the sample. The proportion is 100% for the root node. The percentages under the split nodes add up to give the percentage in their parent node.

Predicted class: Each node shows the predicted class as normalÂ orÂ abnormal. It is the most commonly occurring predictor class in that node but the node might still include observations belonging to the other predictor class as well. This forms the concept ofÂ node impurity.

### Fully grown decision tree

Is this the fully-grown decision tree?

No! Recall that you have grown the decision tree with the default value of cpÂ = 0.05 which ensures that your decision tree doesn’t include any split that does not decrease the overall lack of fit by a factor of 5%.

However, if you change this parameter, you might get a different decision tree. Run the following code-chunk to get the plot of a fully grown decision tree, with aÂ cp = 0

``````## using all the predictors and setting all other arguments to default
cardioFull <- rpart(status ~ . , data = cardio.train, method = "class", cp = 0)

## Using fancyRpartPlot() from "rattle" package
fancyRpartPlot(cardioFull, palettes = c("Greens", "Reds"),sub = "")
``````

The fully grown tree adds two more predictorsÂ thalÂ andÂ oldpeakÂ to the tree that you built earlier. Now you have seen that changing theÂ cp parameter, gives a decision tree of different sizes – more nodes and/or more leaves. At this stage, you might want to ask the following questions:

• Which of the two decision trees you should go ahead with and present to your division’s Chief Data Scientist? The one developed with a default value of cpÂ = 0.01 or the one withÂ cpÂ = 0?
• Does a bigger decision tree present a better classification model or worse?
• Is the default value ofÂ cpÂ = 0.01, the best possible?
• How would you select aÂ cp value that ensures the best-performing decision tree model

There areÂ no thumb rules on how large or small a decision tree should grow. However, you should be aware that:

• AÂ large treeÂ might overfit the data and thus might lead to a model withÂ high variance
• AÂ small tree might miss important parameters and thus might lead to a model with aÂ high bias

So, which of the two decision trees you should present to your division’s Chief Data Scientist? What are the parameters that you can control to build yourÂ bestÂ decision tree? What are theÂ metricsÂ that you can useÂ to justify the performance of your decision tree model? Conversely, what are theÂ metricsÂ that can help you evaluate the performance of your decision tree model?

### Pruning the decision trees

The optimal tree size is chosen adaptively from the training data. The recommended approach is to build a fully-grown decision tree and then extract a nested sub-tree (prune it) in a way that you are left with a tree that has minimal node impurities.

As you have learned in yourÂ in-class module, there are three different metrics to calculate the node impurities that can be used for a givenÂ nodeÂ m:

Gini Index:

A measure of total variance across all the classes in the predictor variable. AÂ smallerÂ value of G indicates a purer or more homogeneous node.

Here,Â PmkÂ gives the proportion of training observations in theÂ mthÂ region that are from theÂ kthÂ class.

Cross-Entropy or Deviance:

Another measure of node impurity:

As with the Gini index, the mthÂ node is purer if the entropyÂ DÂ is smaller.

In your fitted decision tree model, there are two classes in the predictor variable thereforeÂ KÂ = 2 and there areÂ m = 5Â regions.

Misclassification Error:

The fraction of the training observations in theÂ mthÂ node that do not belong to the most common class:

When growing a decision tree,Â Gini IndexÂ orÂ Entropy is typically used to evaluate the quality of the split.

However, for pruning the tree, a Misclassification ErrorÂ is used.

You can now get back to the fully grown decision tree that you built with cpÂ = 0.

TheÂ Complexity Parameter TableÂ will help you evaluate the fitted decision tree model. For your decision treeÂ cardio.train.full, you can print the complexity parameter table usingÂ printcp()Â asÂ well as plot usingÂ plotcp()

TheÂ CPÂ table will help you select the decision tree that minimizes the misclassification error.Â CP table lists down all the trees nested within the fitted tree. The best-nested sub-tree can then be extracted by selectingÂ the corresponding value forÂ cp.

The following code will print the CPÂ table for you:

``````## printing the CP table for the fully-grown tree
printcp(cardioFull)
``````
``````Classification tree:
rpart(formula = status ~ ., data = cardio.train, method = "class",
cp = 0)

Variables actually used in tree construction:
[1] ca      cp      oldpeak thal    thalach

Root node error: 95/208 = 0.45673

n= 208

CP nsplit rel error  xerror     xstd
1 0.536842      0   1.00000 1.00000 0.075622
2 0.063158      1   0.46316 0.52632 0.064872
3 0.031579      3   0.33684 0.38947 0.058056
4 0.015789      4   0.30526 0.35789 0.056138
5 0.000000      6   0.27368 0.36842 0.056794
``````

TheÂ plotcp()Â gives a visual representation of the cross-validation results in an rpart object.

``````## plotting the cp
plotcp(cardioFull, lty = 3, col = 2, upper = "splits" )
``````

### CP table

How do we interpret theÂ cpÂ table? What is your objective here?

Your objective is toÂ pruneÂ the fitted tree i.e. select a nested sub-tree from this fitted tree, such that the cross-validated error or theÂ xerrorÂ is the minimum.

The Complexity table for your decision tree lists down all the trees nested within the fitted tree. The complexity table is printed from the smallest tree possible (nsplit = 0 i.e. no splits) to the largest one (nsplit = 8, eight splits). The number ofÂ nodes included in the sub-tree is always 1+ the number of splits.

For easier reading, the error columns have been scaled so that the first node (nsplitÂ = 0) has an error of 1. In your decision tree the model with no splits makes 123/267 misclassifications, you can multiply the columnsÂ rel error,Â xerror, and xstd by 123 to get the absolute values. In the first column, theÂ complexity parameterÂ has been similarly scaled. From theÂ cp tableÂ we want to select the cp value that minimizes theÂ cross-validated error (xerror).

CP plot

plotcp() gives a visual representation of the CP table. The Y-axis of the plot has theÂ xerrorsÂ and the X-axis has the geometric means of the intervals ofÂ cp values, for which pruning is optimal. The red horizontal line is drawn 1-SE above the minimum of the curve. A good choice ofÂ cp for pruning is typical, the leftmost value for which the mean lies below the red line.

The following code chunk will help you select the best cp from the cp table

``````## selecting the best cp, corresponding to the minimum value in xerror
bestcp <- cardioFull\$cptable[which.min(cardioFull\$cptable[,"xerror"]),"CP"]

## print the best cp
bestcp
``````

0.0157894736842105

You can now use thisÂ bestcpÂ to prune the fully-grown decision tree

``````## Prune the tree using the best cp.
cardio.pruned <- prune(cardioFull, cp = bestcp)
``````
``````## You can now plot the pruned tree
fancyRpartPlot(cardio.pruned, palettes = c("Greens", "Reds"), sub = "")
``````

You can use theÂ summary() function to get a detailed summary of the pruned decision tree. It prints the call, the table shown by printcp, the variable importance (summing to 100), and details for each node (the details depend on the type of tree).

``````## printing the
summary(cardio.pruned)
``````
``````Call:
rpart(formula = status ~ ., data = cardio.train, method = "class",
cp = 0)
n= 208

CP nsplit rel error    xerror       xstd
1 0.53684211      0 1.0000000 1.0000000 0.07562158
2 0.06315789      1 0.4631579 0.5263158 0.06487215
3 0.03157895      3 0.3368421 0.3894737 0.05805554
4 0.01578947      4 0.3052632 0.3578947 0.05613824

Variable importance
cp     thal    exang  thalach       ca  oldpeak trestbps      age
28       17       14       13       12       12        3        2
sex
1

Node number 1: 208 observations,    complexity param=0.5368421
predicted class=normal    expected loss=0.4567308  P(node) =1
class counts:   113    95
probabilities: 0.543 0.457
left son=2 (109 obs) right son=3 (99 obs)
Primary splits:
cp      splits as  LLLR,      improve=34.19697, (0 missing)
thal    splits as  LRR,       improve=31.59722, (0 missing)
exang   splits as  LR,        improve=23.76356, (0 missing)
ca      splits as  LRRR,      improve=21.46291, (0 missing)
thalach < 147.5 to the right, improve=17.90570, (0 missing)
Surrogate splits:
exang   splits as  LR,        agree=0.731, adj=0.434, (0 split)
thal    splits as  LRR,       agree=0.702, adj=0.374, (0 split)
thalach < 148.5 to the right, agree=0.683, adj=0.333, (0 split)
ca      splits as  LRRR,      agree=0.625, adj=0.212, (0 split)
oldpeak < 0.85  to the left,  agree=0.611, adj=0.182, (0 split)

Node number 2: 109 observations,    complexity param=0.03157895
predicted class=normal    expected loss=0.1834862  P(node) =0.5240385
class counts:    89    20
probabilities: 0.817 0.183
left son=4 (98 obs) right son=5 (11 obs)
Primary splits:
oldpeak < 1.95  to the left,  improve=5.018621, (0 missing)
slope   splits as  LRL,       improve=4.913298, (0 missing)
thal    splits as  LRR,       improve=4.888193, (0 missing)
ca      splits as  LRRR,      improve=3.642018, (0 missing)
thalach < 152.5 to the right, improve=3.280350, (0 missing)

Node number 3: 99 observations,    complexity param=0.06315789
predicted class=abnormal  expected loss=0.2424242  P(node) =0.4759615
class counts:    24    75
probabilities: 0.242 0.758
left son=6 (35 obs) right son=7 (64 obs)
Primary splits:
thal    splits as  LRR,       improve=8.002922, (0 missing)
exang   splits as  LR,        improve=7.972659, (0 missing)
ca      splits as  LRRR,      improve=7.539716, (0 missing)
oldpeak < 0.7   to the left,  improve=3.625175, (0 missing)
thalach < 175   to the right, improve=3.354320, (0 missing)
Surrogate splits:
trestbps < 116   to the left,  agree=0.717, adj=0.200, (0 split)
oldpeak  < 0.05  to the left,  agree=0.707, adj=0.171, (0 split)
thalach  < 175   to the right, agree=0.697, adj=0.143, (0 split)
sex      splits as  LR,        agree=0.677, adj=0.086, (0 split)
age      < 69.5  to the right, agree=0.667, adj=0.057, (0 split)

Node number 4: 98 observations
predicted class=normal    expected loss=0.1326531  P(node) =0.4711538
class counts:    85    13
probabilities: 0.867 0.133

Node number 5: 11 observations
predicted class=abnormal  expected loss=0.3636364  P(node) =0.05288462
class counts:     4     7
probabilities: 0.364 0.636

Node number 6: 35 observations,    complexity param=0.06315789
predicted class=normal    expected loss=0.4857143  P(node) =0.1682692
class counts:    18    17
probabilities: 0.514 0.486
left son=12 (20 obs) right son=13 (15 obs)
Primary splits:
ca       splits as  LRRR,      improve=7.619048, (0 missing)
exang    splits as  LR,        improve=6.294925, (0 missing)
trestbps < 126.5 to the right, improve=2.519048, (0 missing)
thalach  < 170   to the right, improve=2.057143, (0 missing)
age      < 53.5  to the left,  improve=1.866667, (0 missing)
Surrogate splits:
thalach  < 134   to the right, agree=0.743, adj=0.400, (0 split)
trestbps < 129   to the right, agree=0.714, adj=0.333, (0 split)
exang    splits as  LR,        agree=0.686, adj=0.267, (0 split)
oldpeak  < 1.7   to the left,  agree=0.686, adj=0.267, (0 split)
age      < 62.5  to the left,  agree=0.657, adj=0.200, (0 split)

Node number 7: 64 observations
predicted class=abnormal  expected loss=0.09375  P(node) =0.3076923
class counts:     6    58
probabilities: 0.094 0.906

Node number 12: 20 observations
predicted class=normal    expected loss=0.2  P(node) =0.09615385
class counts:    16     4
probabilities: 0.800 0.200

Node number 13: 15 observations
predicted class=abnormal  expected loss=0.1333333  P(node) =0.07211538
class counts:     2    13
probabilities: 0.133 0.867
``````

### Evaluating decision tree models

You can now use theÂ predictÂ function inÂ rpartÂ package to predict theÂ statusÂ of patients included in the test dataÂ cardio.test

The following code-chunk predicts the status values for test data and will also print the confusion matrix for actual v/s. predicted values:

``````## You can now use your pruned tree model to predict the status for your test data
cardio.predict <- predict(cardio.pruned, cardio.test, type = "class")
``````

You should now evaluate the performance of your model on the test data. You will use yourÂ Confusion MatrixÂ and calculate theÂ Classification ErrorÂ in the predictions:

``````# confusion matrix (training data)
conf.matrix <- table(cardio.test\$status, cardio.predict)
rownames(conf.matrix) <- paste("Actual", rownames(conf.matrix), sep = ":")
colnames(conf.matrix) <- paste("Predicted", colnames(conf.matrix), sep = ":")
print(conf.matrix)
``````
``````                 cardio.predict
Predicted:normal Predicted:abnormal
Actual:normal                 40                  7
Actual:abnormal               14                 28
``````

You can calculate the classification error as:

``````## caclulating the classification error
round((14 + 7)/89,3)
``````
``0.236``

So, your decision tree has a 23.6% prediction error. In other words, your model has been able to classify the patients as normalÂ orÂ abnormalÂ with an accuracy ofÂ 76.4%. Your division’sÂ Chief Data Scientist should be impressed. Also, you have a classification model that you can very easily explain to doctors.

However, before we wind up, here is a small exercise for you.

#### Small Exercise:

Decision tree models can suffer from extremely high variance. A small change in the training data can give you very different results. This short exercise is designed to make this point. In the code chunk given below change the values, one at a time,Â for the following parameters, run the code, and then observe how the decision tree model changes:

set.seed (a): Set the seed to a different number: ‘1234’ or ‘1729’ or ‘9999’ or whatever you like

Training set proportion (p): Set the proportion to different numbers: ‘70%’ or ‘80%’, ‘90%’ or whatever you like

You can go ahead and use the code till the calculation of the prediction error but even plotting the fitted tree would help!

``````## You should keep the original data frame intact so let's make a copy cardioplay
cardioplay <- cardio

## you set the seed to ensure that you get the same training v/s. test split every time you run the code
## Keeping all else constant, you should change the seed from '1234' to any other number
a <- as.numeric(1234)

## randomly extract row numbers in cardio dataset which will be included in the training set
## Keeping all else constant, you should change the proportion from '50%' to any other proportion
p <- as.numeric(0.50)
``````
``````## You don't need to make any changes in this code-chunk
## Make changes in the code-chunk just above and observe the changes in the output of this code-chunk

## seed
set.seed(a)

## rows in training data
trainset <- sample(1:nrow(cardioplay), round(p*nrow(cardioplay),0))
cardioplay.train <- cardio[trainset, ]

## rows in test data
cardioplay.test <- cardio[-trainset,  ]

## fit the tree
cardioplay.train.fit <- rpart(status ~ . , data = cardioplay.train, method = "class")

## plot the tree
fancyRpartPlot(cardioplay.train.fit, palettes = c("Greens", "Reds"), sub = "")

``````

### Conclusion

Now, you have a good understanding of how to perform the exploratory data analysis and prepare your dataset, before you can set out to build a decision tree. You are also familiar with various functions in the rpart package with which you can build decision trees, plot the trees, and prune decision trees to build. As we have discussed earlier, there are other tree-based approaches such asÂ Bagging,Â Random Forests,Â andÂ BoostingÂ whichÂ improve the accuracy.

You are all set to start practicing exercises on these advanced topics!

##### Up for a Weekly Dose of Data Science?

Subscribe to our weekly newsletter & stay up-to-date with current data science news, blogs, and resources.

#### Discover more from Data Science Dojo

Subscribe to get the latest updates on AI, Data Science, LLMs, and Machine Learning.
